Specifications
1.good price with perfect quality2.strong working ability
3.long working life and high efficiency
d-12 laboratory flotation
The machine can be used to separate nonferrous metal, ferrous metal, noble metal, nonmetallic mine, chemical material and recycle mine. It features high inhalation and low power. Each chute can inhale gas, sink magma and separate - there is no need for accessory equipments. It is easy to change the flow chart. The cycling way of magma is very reasonable and it can reduce the impurities to a great extent. There is automatic equipment on the magma surface. The machine is easy to adjust; the upward one makes the magma cycle upward and the downward one makes the magma cycle downward.
Technical Parameters of Model SF Flotation Machine
|
Model |
SF0.37 |
SF0.7 |
SF1.2 |
SF2.8 |
SF4 |
|
Tank Volume(m3) |
0.37 |
0.7 |
1.2 |
2.8 |
4 |
|
Impeller Dia(mm) |
300 |
350 |
450 |
550 |
650 |
|
Capacity(m3/min) |
0.2-0.4 |
0.3-0.9 |
0.6-1.2 |
1.5-3.5 |
0.5-4 |
|
Impeller Rotate Speed(m3/min) |
352 |
400 |
312 |
268 |
238 |
|
Motor |
Model |
1-Y90L-4 |
1-Y100L2-4 |
1-Y132M2-6 |
1-Y160L-6 |
1-Y180L-6 |
2-Y90S-4 |
2-Y90S-4 |
2-Y90S-4 |
2-Y90S-4 |
2-Y90L-4 |
||
Power(Kw) |
1-1.5 |
1-3 |
1-5.5 |
1-11 |
1-15 |
|
2-1.1 |
2-1.1 |
2-1.1 |
2-1.1 |
2-1.5 |
||
Overall Dimension(mm) |
700×700×750 |
900×820×950 |
1100×1100×1100 |
1700×1600×1150 |
1850×2050×1200 |
|
Unit Weight(kg) |
468 |
600 |
1373 |
2338 |
2660 |
|
Technical Parameters of XJK Series Flotation Machinery:
|
Model |
XJK-0.35(3A) |
XJK-0.62(4A) |
XJK-1.1(5A) |
XJK-2.8(6A) |
XJK-5.8(7A) |
||
Effective Volume(m3) |
0.35 |
0.62 |
1.1 |
2.8 |
5.8 |
||
Capacity(m3/min) |
0.18~0.4 |
0.3~0.9 |
0.6~1.6 |
1.5~3.5 |
3~7 |
||
Rotate Speed(r/min) |
470 |
400 |
330 |
280 |
240 |
||
Impeller Dia (mm) |
300 |
350 |
500 |
600 |
750 |
||
Motor |
Model |
Rotator |
Y90L-4 |
Y100L2-4 |
Y132M2-6 |
Y160L-6 |
Y200L2-6(Y225M-6) |
Scraper |
Y90S-4 |
Y90S-4 |
Y90S-4 |
Y90S-4 |
Y90L-4 |
||
Power(Kw) |
Impeller Motor |
1.5 |
3 |
5.5 |
11 |
22(30) |
|
Scraper Motor |
1.1 |
1.1 |
1.1 |
1.1 |
1.5 |
||
Weight:(t/Single Tank) |
0.43 |
0.86 |
1.38 |
2.33 |
3.533 |
||
d-12 laboratory flotation machine sale
Contact Add:No.33 Shenxia Road, Malu Industrial Park, Jiading District, Shanghai, China
