DPB-350 High quality Automatic blister packing machine
Specifications:
1.high precision and good exchangeability
ucer adapts parallel-axes bevel wheel
3.multi-purpose machine
Features:
1)machine-tool track type of casting machine-base, taken these processing like backfire, maturing, High benchmark and without distortion.
2)Each box of section processed through professional equipment to assure high precision and good exchangeability.
3)Forming,sealing,slitting etc.parts are all could be adjust freely on the track with triangle string and flat string, strong applicability. small oversize, save installation space.
4)Reducer adapts parallel-axes bevel wheel, To avoid loose and smooth between chain or strap when it is driving.
5)Stroke can be adjust freely, widely used, ease of operation, stable running.
6)Mould located by male pin, ease and accuracy of changing mould. Product any sizes and shapes of strip by changing the mould on the same machine, and it also can pack for liquid if liquid filling device equipped.It is multi-purpose machine.
7)It adapts up and down net pattern concavo-convex to conjugate, multi-step air cylinder, double-heat sealing. Quality sealing.
Main technical parameters:
Cutting Frequency(times/min) |
I: less than 70 ; II: less than 50 |
Capacity( strip/h ) |
280 standard 50*80 |
Max shaping areas and depth(mm) |
245*160*12 |
Stroke(mm) |
20-120(can be manufactured as user's requirements) |
Standard Sheet(mm) |
80X57(can be manufactured as user's requirements) |
Max. Width of the material |
350 |
Air Pressure(kw) |
0.4-0.6 |
Total power |
380V/220V 50Hz 9.95kw |
PVC hard pieces(mm) |
0.15-0.5X320 |
PTP Aluminum Foil(mm) |
0.02-0.035X320 |
Dialysis Paper(mm) |
50-100gX320 |
Mould Cooling |
Tap water or Back water |
Overall Dimensions(mm) |
4200x840x1700mm |
weight(kg) |
1800 |
Pictures:
DPB-350 blister packing machinee Packaging: Wooden Package
DPB-350 blister packing machine Shipping: By Sea, By Air and By Train
The Service of DPB-350 blister packing machine:
Technical suppport and Training support
Engineers available to service machinery overseas
Liaoyang Zhonglian Pharmaceutical Machinery Co., Ltd is situated in Liaoyang City of Liaoning Province, earliest engaged in the production of pharmaceutical machinery in China.Zhonglian is specially engaged
in the production of pharmaceutical machinery, centrifugal equipment and packaging machine, owns many
years of experience in professional production, enjoys advanced technology and high quality equipment,
developed and manufactured multiple pharmaceutical machine, multiple packaging machine and multiple hi-tech centrifugal equipment, including centrifugal separator machine, mixing machine, dryer machine, coating machine, powder packaging machine, granular packaging machine, blister packaging machine. disc centrifuge,
tubular centrifuge, tripod series centrifuge and flat plate centrifuge, which are widely applied in pharmaceutical,
chemical, food, smelting and other industries. Our company is supported and well received by a wide range of users with reliable quality and excellent after-sales service.
