Help CenterPVC Injection Moulding Machine (1/2 Color)
Related Products
-
PVC Air Blowing Injection Moulding Machine (1/2 Color)US$ 21000.00 - 21000.00MOQ: 1 Set -
Double Color Pvc Air Blowing Sandals and Slippers Injection MachineUS$ 1 - 1.1MOQ: 1 Set
-
Plastic Rotary 30 Station Used Pvc Air Blowing MachineUS$ 1 - 1.1MOQ: 1 Set
-
Single Color Rotary Used Pvc Air Blowing Machine for SaleUS$ 1 - 1.1MOQ: 1 Set
-
Good Condition Pvc/tpr Used Pvc Air Blowing Machine for Sale Quality ChoiceUS$ 1 - 1.1MOQ: 1 Set
HONKING Machinery Equipment Co., Ltd. Is a premier manufacturer of shoes making machine and related equipments.
Our factory is located in Dongguan, China which is called as "World Factory" and "Shoes Capital of Asia". We focus on the innovation, research and make of shoe making machine, and also work hard to solve various kinds of injection technology. We have machine for all kinds of material which have different type and hardness, such as TPR, PVC, TPU, TR, EVA, PU, RUBBER and so on.
Our professional products are as followed:
1. PVC shoes air blowing machine (1/2 color)
2. PVC jelly shoes injection moulding machine (1/2/3 color)
3. Rain boots injection moulding machine(1/2 color)
4. Rotary TPR/PVC/TPU/TR outsole injection moulding machine (1/2/3 color)
5. Vertical TPR/PVC/TPU/TR injection moulding machine (1/2 color)
6. EVA shoes injection moulding machine (1/2 color)
7. RUBBER injection moulding machine
8. Silicone injection moulding machine
9. PU injection moulding machine
10. PVC upper injection moulding machine (1/2/3 color)
We have been working well exporting to Europe, Africa, Asia, South America, Middle East, Russia, Turkey and so on. We believe that our success depends on your satisfaction with our products. We always adhere to the principle of "Quality First, Customer Supreme" and providing our best sales services for our customers. Our team of experienced engineers strives to continuously improve our technologies-----from hardware design to machine components making them the most durable and reliable in the marketplace. Our shoes machines are thoroughly tested, both in the design and throughout the entire production process.
1. This machine is used to produce various kinds of one color soles, slippers, sandals, short-height boots and it is special for producing sports shoes and leather shoes in all plastic.
2. It is suitable for all kinds of thermoplastic raw materials, foaming or non-foaming, such as PVC, TPR, PCU.
3. The well-interconnected oil circuit by electric control can reduce waiting time, quicken production rate, and promote productivity.
4. Air blowing system device with air release function of mold makes the products lightweight, soft with gloss surface and high value.
5. Injection pressure and speed of each station can be controlled individually according to different materials and molds by PLC system; It can use different molds at the same machine. It saves the time of mold-change and extends the cooling time.
Specification
| ITEM | UNIT | HM-188 |
| Screw diameter | mm | 65 |
| Max. injection volume | cc | 650 |
| Heating bands power | kw | 7 |
| Temperature control | point | 4 |
| Screw rotation speed | r.p.m | 0-200 |
| Max. Injection stroke | mm | 210 |
| Motor | Kw/hp | 18.5/25 |
| Clamping force | ton | 80 |
| Work stations | stations | 24 |
| Space for mould | mm(LxWxH) | 600x280x280 |
| Total Electricity | KW | 25.5 |
| Machine dimension | mm(LxWxH) | 4200x3500x1650 |
| Installation dimension | mm(LxWxH) | 4600x3600x2300 |
| Machine weight | kg | 6000 |
Remarks:
1,The machine one year warranty;
2,Installation place we will send technical personnel to the buyer for 3-7 days;
4, The buyer is responsible for visas and orund-trip air tickets and shall be responsible for the food and lodging;
5,More than 7 days, the buyer will provide us engineer daily $100;
Any confusion, pls. feel free to contact us . Looking forward to cooperating with YOU!
