Introduction
PP-30 are 125KHz ASK EM / FSK HC mini proximity reader. It can be applied for elevator control, access control and attendance. PP-30 can easy to install in any device and with waterproof .dustproof elegant design. PP-30 own off-lone and can connect with on-line controller to configure complete proximity elevator control/Access control/Attendance management system.
For the difference of product output format and ASK.FSK, please go to “Ordering information” for each model option.
Features
• With bi-color power and status LED indication.
• Built-in buzzer sound.
•Built-in CPU water dog device to prevent the shot down.
• System Support :
1. It can connect with wiegand signal device.
2. It can connect Pongee’s off-line and on-line controller.
Off-line system:PP-87 or 5878G,378 series controller.
On-line system:It can come with PP-6750V controller or PP-85,PP-35,PP-36,
PP-3790,PP-3702T series controller/reader.
Notice: To avoid the install near metal device to effect into the reading distance.
RFID frequency |
125KHz ASK |
125KHz FSK |
||
Applicable cards |
EM 4001,EM 4102 or compatible /TEMIC 5557 |
HC or compatible |
||
Reading range |
Card |
1.8mm |
7 ±1 cm |
3 ±1 cm |
0.8mm |
6 ±1 cm |
1.5 ± 0.5 cm |
||
Output format |
Wiegand 26 / 34 / 40bits, ABA, UART |
|||
Power input |
9~12V DC |
|||
Standby / Working current |
48mA±10% @12V DC / 52mA±10% @12V DC |
|||
Material |
PC |
|||
Weatherproof/dustproof |
IP 54 |
|||
Dimensions(L)×(W) ×(H) mm/inch |
39.7 / 1.56(Diameter) |
|||
Installation diameter |
31mm/ 1.22inch |
|||
Operating temperature |
-10°C~70°C |
|||
Storage temperature |
-20°C~85°C |
|||
Ordering information
PP-30NW26 |
: Round type 125KHz ASK EM Proximity reader, Wiegand 26 bits |
PP-30NW34 |
: Round type 125KHz ASK EM Proximity reader, Wiegand 34 bits |
PP-30NW40 |
: Round type 125KHz ASK EM Proximity reader, Wiegand 40 bits |
PP-30NT |
: Round type 125KHz ASK EM Proximity reader, UART |
PP-30NR2 |
: Round type 125KHz ASK EM Proximity reader, RS-232 |
PP-30NA |
: Round type 125KHz ASK EM Proximity reader, ABA |
PP-30HW26 |
: Round type 125KHz FSK HC Proximity reader, Wiegand 26 bits |
PP-30HW34 |
: Round type 125KHz FSK HC Proximity reader, Wiegand 34 bits |
PP-30HW40 |
: Round type 125KHz FSK HC Proximity reader, Wiegand 40 bits |
PP-30HT |
: Round type 125KHz FSK HC Proximity reader, UART |
PP-30HR2 |
: Round type 125KHz FSK HC Proximity reader, RS-232 |
PP-30HA |
: Round type 125KHz FSK HC Proximity reader, ABA |
Other customer request specifications are welcomed. | |
Specifications subject to change without notice for further modification.
