Pet Stretch Blowing Machinery For 18.9l
ZG100 PET blow moulding machine for large PET bottles is specially designed to produce 5-gallon PET container and 25L wide mouth jar. Its max output is up to 90 BPH for 5-gallon bottle and even could reach 120 bottles per hour for the one way used thin wall 5 gallon bottles.
ZG100 PET blow moulding machine consists of main unit and rotary infrared heater. The ordinary quartz lamp cannot heat preform ideally because the preform wall is excessively thick. The infrared heater with high penetrative force can heat the inside and outside of preform simultaneously and keep preform in even heating, therefore high shaping quality.
1. Special design for PET Gallon Bottle up to 6 Gallon
2. Produce wide mouth jar up to 25 liter with neck size up to 200mm.
3. Using Infrared reheat units to achieve uniform heating throughout the wall of preform
4. Adopt special designed preform heating system to ensure the optimal heating effect for 730g thick-wall preform
5. Special designed fan-cooling system in the heating channels to keep the oven with constant temperature and ensure the preform can be heated completely.
6. Water cooling system ensures the quality of preform neck.
7. Up to 90 bottles/hour using one-cavity mold for 5-gallon bottle
8. Use advanced PLC control system with counting function and time-control precision to 0.01second, and a use-friendly panel.
9. Equipped with special designed air storage units
10.Simple installation & startup adjustment
Pet Stretch Blowing Machinery For 18.9l
General |
ZG-100 |
Theoretical Output (pcs/hr) |
90-180pcs/hr |
Installed capacity(kw) |
35kw |
ntainer volume |
30L |
Blow Pressure (Mpa) |
≤3.5Mpa |
Working Pressure (Mpa) |
≤1.0Mpa |
ntainer diameter -height(mm) |
Ø 280mmXH450 |
Mould thickness(mm) |
300-400 |
Machine Weight(kg) |
1500 |
Main Machine(mm) |
2200*700*2250 |
Heater(mm) |
2200*700*1750 |
- Enquiry: contact us by email, phone call, fax, Instant tools (Trademanager, MSN, Skype) and let us know your enquiry.
- Discussion: specify the items you desire, confirm specification; OEM/ODM consultation.
- Quotation: Prices offered and accepted.
- Place order as per contract or discussion.
- Proforma invoice offered to double confirm the order for both-side records.
- Payment settled.
- Order completed under our arrangement.
- Goods shipped as per contracted term.
- Goods arrive at local port or warehouse, depending on contracted term.
