Help CenterRJ45 Top Entry 1*4 Port PCB Socket/Connector
Related Products
-
Side Entry RJ45 PCB Modular Unshield JackUS$ 0.04 - 0.79MOQ: 5000 Pieces -
Side Entry 10P RJ45 PCB JackUS$ 0.079 - 0.1MOQ: 1000 Pieces
-
Best Rj45 Pcb Female Unshield ConnectorUS$ 0.06 - 0.7MOQ: 1500 Pieces
-
RJ45 Network Telephone ConnectorUS$ 0.1 - 2MOQ: 5000 Pieces
-
RJ45 10p Network Lan Modular PCB Jack With 1*2portUS$ 0.1 - 2MOQ: 5000 Pieces
Specifications
1.RJ45 Top Entry Telephone Modular PCB Connector/Socket with Round Pin Modular PCB Jack2.UL,RoHS,ISO9001-2000
Product Name: Network Connector/RJ45 Modular PCB Jack
Item No.: SC217-5224-8P-1*4
Description:
Top Entry modular pcb jack without shield, 8p2c, 8p4c 8p6c or 8p8c(number of 8 passing through the golden needles, amount of 2, 4, 6 or 8 needles) with Stamp Pin(Flat Pin)
No.of Ports:1*4 Port
Angle: 180 Degree
Color: Black, also can requested by customers
Specification
Electrical
1. Current Rating: 1.5 amps
2. Voltage Rating: 125vac
3. Insulation Resistance: 500mΩmin
4. Contact Resistance: 30mΩmax
5. Withstanding Voltage: AC 1000V RMS 50Hz or 60Hz 1 min
Mechanical
1. Insertion Force: 2.2KG. F max
2. Retention Strength: 7.7KG. F min between jack and plug
3. Durability: 600 mating cycles min
Material
1. Housing: ABS RESIN(UL94V-0)
PBT(UL94V-0)(Common type)
PA66(UL94V-0)
PA46(UL94V-0)
2. Contact Wire: Diameter 0.45mm phosphor bronze gold plating over Nickel
3. Shield: 0.20~0.25mm thickness brass with tin plated
4. Gold Plating: Fu", +3u",6u",15u",30u" or 50u"
