Side entry RJ45 10P Modular PCB Jack

Specifications

1.Side entry RJ45 10P Modular PCB Jack
2.UL,RoHS,ISO9001-2000

Description:
Side entry RJ45 PCB connector with 0.46mm round pin
Without shielding.



Electrical:
Rated current: 1.5A
Rated voltage: 125VAC
Insulation resistance: 500MΩmin
Contact resistance: 30MΩmax

Withstanding voltage: 1000VAC RMS, 50 or 60Hz 1 Min



Mechanical:
Insertion force: 2.2kgf max

Retention strength: 7.7kgf min between jack and plug
Durability: 600 mating cycles minimum



Materials:

Housing:  PBT (UL94V-0), PA66 (UL94V-0), and PA46 (UL94V-0)
2. Contact Wire: Diameter 0.46mm phosphor bronze gold plating over
Nickel
3.Gold Plating: Fu inch, 3u inch, 6u inch, 15u inch, 30u inch, 50u inch
