Muti-port RJ45 Side Entry Modular PCB Jack

Muti-port RJ45 Side Entry Modular PCB Jack thumbnail-1
Muti-port RJ45 Side Entry Modular PCB Jack photo-1
US$ 0.1 - 2 MOQ: 5000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
CSCE
Model Number:
SC241-5225-8P-1*4-90
Contact Supplier Request Quote Chat Now
Yueqing Shichuang Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai or Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name CSCE
Model Number SC241-5225-8P-1*4-90

Specifications

1.RJ45 Side entry Network Modular Jack with 1*4 ports,90 degree.
2.UL,RoHS,ISO9001-2000

Product Name:  RJ45 Muti-port Modular PCB Jack

Item No.: SC241-5225-8P-1*4-90



Description:
Side Entry modular PCB jack without shield, 8p2c, 8p4c 8p6c or 8p8c(number of 8 passing through the golden needles, amount of 2, 4, 6 or 8 needles) with Stamp Pin(Flat Pin)

No.of Ports:1*4 Port
Angle:90 Degree

Specification
Electrical
1. Current Rating: 1.5 amps
2. Voltage Rating: 125vac
3. Insulation Resistance: 500mΩmin
4. Contact Resistance: 30mΩmax
5. Withstanding Voltage: AC 1000V RMS 50Hz or 60Hz 1 min



Mechanical
1. Insertion Force: 2.2KG. F max
2. Retention Strength: 7.7KG. F min between jack and plug
3. Durability: 600 mating cycles min



Material
1. Housing: ABS RESIN(UL94V-0)
PBT(UL94V-0)(Common type)
PA66(UL94V-0)
PA46(UL94V-0)
2. Contact Wire: Diameter 0.45mm phosphor bronze gold plating over Nickel

3. Shield: 0.20~0.25mm thickness brass with tin plated
4. Gold Plating: Fu", +3u",6u",15u",30u" or 50u"
