Standard Reagent Type Lab Water Purification System/Lab Ultrapure Water System/Purifier/Machine/Equipment(single stage RO)

Specifications

Lab standard reagent type ultrapure water purifier
1.Modularization
2.High cost effective
3.Good function,Favorable price

Lab standard reagent type ultrapure water purifier/water purification system (single stage RO)



FBZ0501-UP   FBZ1001-UP   FBZ1501-UP   FBZ2001-UP  FBZ3001-UP

Characteristics

1, Automatic microcomputer control system, 5.1 inches LCD key-press screen (touch screen is optional), powerful while only six touch keys. animation displays friendly.

2, One machine can produce 2 or 3 kind of water: 3^rd, 2^nd, 1^st Type laboratory water (water quality is optional).

3, Three way online monitoring, monitor inlet water, RO water, ultra pure water quality in real time.

4, Online test of PH.

5, Full automatic complete machine sterilization.

6,  It will alarm when the water quality is overproof or the machine leak water.

7,  Timing automatic/manual flushing; it’ll alarm if full of water; automatic power-off when short of water, automatic inner cycle, automatic detection of faults.

8,  When power-on, the system will quickly reach to 18.25MΩ/cm@ 25°C stable water quality, water saving, energy saving, time saving.

9, Specially set up double stage passwords: factory’s and customer’s, the system settings are protected by passwords to prevent unauthorized modification.

10, Show consumables’ usage and the remaining time, automatic remind of due replacing consumables, to avoid decline of water quality.

11,  RS232 interface record, print, computer monitor history water intake

record (optional).

12, Specially set up function: Get water in fixed time and fixed quality.

(time: 1-99min; fixed quality: 0.1-18.2 MΩ. cm).

13,  All pipelines have been certified by NSF, Bran-new quick plug-in joints, modularity, more convenient to replace and maintain filter columns.

14, Core components are imported from International brands and they’re controlled automatically by microcomputer.

Technical parameters

1. Inlet water: general municipal tap water; Raw water TDS≤250PPm
2. Inlet water pressure/water temperature:0.15-0.5Mp/ 5-40°C

3. Producing water:

Resistivity/Conductivity ≥18.25MΩ.cm@25°c/≤0.055μS/cm;

Total Organic Carbon(TOC)≤20PPb;

Microbe <1CFU/ml;

Particle>0.22μm, <1piece/ml(Optional).
4. Water flow rate:1-2.0L/min

5. Power supply: 220VAC/50HZ; Power: 50W;

6. Size:430*501*530mm; Net Weight: 30KG (30L/h-50KG);

Note

1,The above data are the technical parameters of Flom satandard reagent type single stage FBZ 5-30(01) L/h ultrapure water machine; if users' feed water TDS>250PPm or need more water, they can choose Flom double stage FBZ 5-20(02)L/h ultrapure water machine.

2,If user has pure water or distilled water with conductivity <10μs/cm, they can use FBZ entering distilled water type ultrapure water machine, Its water production can reach 20-90 L/h, and the producing water parameters are the same with the ones in table above.

Application

used for making buffer solution, analysis and test of atomic absorption(AA), atomic fluorescence(AFS), High Performance Liquid Chromatography(HPLC), mass spectral analysis(MC), Inductively Coupled Plasma (ICP),etc
