Brick Machine Auto Cutting Machine Type TL-QPJ-CB

Dimension L x W x H

2,800 x 3,250 x 1,550    (mm)

Board Pushing Frequency

41    (1/min)

Maximum Cutting Height

H ≤  330  (mm)

Main Power

5.5  kw

Weight

≈  1800     (kg)

Standard Set

Mechanical Jacks System: cutting wire set, stand frame, brick-pushing to cut device, reduction device etc. Electric Auto-Control System: PLC coding component, pneumatic components, mini-roller motors etc.

Features of Type TL-QPJ-CB

The machine adorpted PLC contol & equipped with horniness durable guide rod key parts etc and the advanced guiding bearing technology, works in way of rolling attrition instead of oiling lubrication pushing the clay strips forward and cutting them to required size. Since there is no need to fill the oil to the working table that causes the labor & material cost reduced and the production efficiency increased. Compare with similar kind of other brand, the machine of type TL-QPJ-CB is much better in many aspect of rational & compact structure, stable & smooth running, safety & easy operating or maintenance, high quality with exactly geometry cutting size of the green bricks and without the faulty of winding deformed etc which some other cutting machine may often occur. The service life is also as longer as 3-5 times above, it is the suitable equipment for both varied kinds of hollow bricks and solid bricks.
