Ceramic Tiles Press Machine

Name: Ceramic Tiles Press Machine
Brand: Tele Machine
SKU: 104804301
Availability: InStock

US$ 85,000 - 86,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Tele Machine

Model Number:

ceramic tile making machine TL-YZJ-260

Foshan Tech-Leader Machinery Equipment Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN / FOSHAN / GUANGZHOU

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Tele Machine

Model Number ceramic tile making machine TL-YZJ-260

After-sales Service Provided Engineers available to service machinery overseas

Product Description

Major Technical Parameters of Hydraulic Tile Press Type TL-YZJ-260

Dimension L x W x H (mm)	Main Cylinder Max. Pressing Force (k n)	Working Table L x W (mm)	Motor Power (kw)
1,600 x 750 x 3,055	2600	700 x 900	22
Working Frequency. (1/min)	Lower Cylinder Ejecting Force (k n)	Lower Cylinder Ejecting Stroke (mm)	Net Weight (kg)
8~10	110	120	≈ 9000

Features of This Type
1. Mainly for producing special-shape ceramic tiles or ultra-thick tiles, like corner tiles, split rocks etc. by adopting dry pressed-forming process, to get more trendy and characteristic constructional materials. 2. Patterned technology guarantees good performances and easy dealing with varied technical parameters of different kind special ceramics, like angle, thickness, pressing-force, feeding-conditions during work. 3. Matched with the corner tiles further processing equipment & TL-PZJ-PY splitting machine to realize corner tiles whole process & split rocksproduction.
