brick making machine Hydraulic Bricks Press Type TL-YZJ-260
Demension: L x W x Hmm |
1,600x750x3,055 |
Main Cylinder Max .Pressing Force (kn) |
2600 |
Main Cylinder Max. Pressure (mpa) |
37 |
Lower Cylinder Ejecting Force (kn) |
110 |
Main Cylinder Max. Stroke (mm) |
260 |
Lower Cylinder Ejecting Stroke (mm) |
120 |
Main Power (kw) |
22 |
Net Weight (kg) |
9000 |
|
Standard Set: Mechanical Jacks System: Four-beam & two-pillar frame, main cylinder, pneumatic, components, two-way and straight-line moving guider, whole sealing hydraulic system, and powder-feeding hydraulic-driving system etc. Electric Auto-Control System: Japanese MISUBISHI PLC coding component, L-size color liquid crystal display and man-machine control panel etc. | |
|
Features of Type TL-YZJ-260 The Press Type TL-YZJ-260 is special designed and made of leading technology to produce special ceramic tiles, like corner tiles, ultra-thick or special shape ceramic etc. by adopting powder materials compacting pressed-forming process. Through which the required anger or thickness or shape of tiles are achieved, which are smooth in surface, precise in dimensions with high inner density and strength. Since the hydraulic drove powder-feeding system is unique designed of easy-to-adjust but notable low costs compared with other complex and expensive one, the remarkable features of the TL-YZJ-260 Press are not only its guaranteed performance but also its high performance-price ratio dealing with varied technical parameters of different special tiles to be made like the tiles anger, tiles thick, pressing-force, or feeding-conditions etc. It is truly the best ideal equipment for special ceramics. | |
