Brick Cutting Machine:
1.Automatic vertical synchronous brick cutting machine.
2. Superior for cutting stood conveying tiles such as Split tiles, clay bricks etc
3. Series cutters suit for diffierent types bricks, optional according to your requirement.
FOSHAN TECH-LEADER MACHINERY EQUIPMENT CO.,LTD(FOSHAN TELE) | |||||
Product | |||||
|
Features of This Type
1. Patterned technology specially made for the stood conveying and cutting process synchronously matched with high-grade and high-volume extruded wet-forming green ceramic tiles and bricks, especially for making the high-class split tiles, woody tiles, clay bricks etc. 2. Superior features of 6N+2L+3H ensure high quality and efficient production. (6N--No cutting leftovers & its recycle process, No man-made errors, No sliding friction surface default, No kerosene used & its pollution problem. 2L--Low worker’s & material’s cost. 3H--High cutting precision, out put and performance-price ratio). Multi-acting cutting unit of SF type can servo driven, controlled and adjustable for double-acting or treble-acting according to the specific requirement. | |||||
|
Production Line Clay Material Preparation line+ Clay Extruder + Brick Cutter/roof tile cutter + drying&firing line | |||||
|
Dimension L x W x H (mm) |
Cutting Frequency (Matched with the extruder) (1/min) |
Cutting Precision (mm) |
|||
LSTB-A |
2,500x800x1,400 |
1 ~ 60 |
±1 |
||
|
Motor Power (kw) |
Cutting Length/ Width Range (mm) |
Net Weight (kg) |
|||
LSTB-A |
1.9 |
200 ~350 / ≤180 |
≈ 1000 |
||
|
|
|
|
|||
Auto Wet Green Tile Cutter |
Vertical Synchronous Cutter |
Horizontal Synchronous Cutter |
|||
|
|
|
|
|||
About Us | |||||
|
TELE MACHINE, THE TECH-LEADER COMPANY ownsnumerous patents and leading technology in the field, and as The State High-Tech Enterprises, Guangdong Civil-Run S & T Enterprises and Intellectual Property Right Pilot Enterprises in Foshan city has continuous innovated & developed 3-series of ceramic tiles and bricks making machinery, from Material Preparation Machine Series, Forming or Shaping Machine Series, to Production Line & Its Auto Auxiliary System Series which achieve requirements of high quality & efficiency, energy or labor saving & carbon emission reduction, and clean production & environmental protection modern manufacture for Roofing Tile, Ceramic Plate, Terracotta Panel, Clay Brick, Hollow Brick, Split Tile and other market-leading ceramics and building material.
| |||||
Products Made By Our Machines :
