Help CenterFoshan Tele Machine Companies Looking for Agents of Auto Cutting Machine , Design for Cutting TypeTL-QDJ-QP
Related Products
-
Factory Price Oill Free Vertical Synchronous Cutter , China Cutter on Sale Type TL-QDJ-LSTB-SFNegotiableMOQ: 1 Set -
TL-SYX-J Specially Made for Various Corner Tiles Glazing Making Machine in ChinaUS$ 43,500 - 46,550MOQ: 1 Set
-
New Products Hydraulic Splitting Machine , Bricks Splitting Machine for Small BusinessUS$ 18,900 - 20,000MOQ: 1 Set
-
High - Class Automatic Splitting Machine Prices , Splitting Machines for Sale on Website Type TL-PZJ-ATUS$ 22,980 - 24,000MOQ: 1 Set
-
Foshan Tele Synchronous Refractory Cutter Machinery Without Cutting Left Type TL-QDJ-NCNegotiableMOQ: 1 Set
Major Technical Parameters of Auto Cutting Machine TypeTL-QDJ-QP | |||
| |||
Dimension L x W x H (mm) |
Cutting Frequency (Matched with the extruder) (1/min) |
Capacity (Pieces/min) |
Cutting Precision (mm) |
2,800 x 3,250 x 1,550 |
1 ~ 40 |
2 ~ 720 |
±1 |
Motor Power (k w) |
Cutting Width Range (mm) |
Cutting Height Range (mm) |
Net Weight (kg) |
5.5 |
40 ~ 1280 |
≤ 300 |
≈ 1800 |
| |||
Features of This Type | |||
|
1. The TL-QDJ-QT specially made for automatic strip cutting process of extruded wet-forming clay bricks or hollow bricks, It with many advantages as wide use adjustable cutting lengths, high precision & efficiency etc. 2. Matched with TL-QDJ-QP cutter in automatic geometry cutting process of extruded wet-forming clay bricks or hollow bricks and adopted PLC control & equipped with horniness durable guide rod key parts and the advanced guiding bearing technology, works in way of rolling attrition to push and cut to required size. | |||
