China scrap metal press machine / lowest price steel extrusion press machine

Major Technical Parameter

Dimension L x W x H: 8,520 x 1,500 x 2,770 (mm)

Working Frequency:12~14 (times/min)

Out Put/ Shift (8 hours a shift): 5,760 ~ 6,720 (pieces/shift)

Motor Power :7.5(kw)

Working Table L x W: 380x500(mm)

Main Cylinder Max. Pressure: 1200(kn)

Pressure Stroke / Max. Stroke:8/280(mm)

Adjusting-Height for Mould-Mounting: 10(mm)

Net Weight :9000(kg)

Features of Type   roofing tile pressTL-AUTOYWJ-IW

1. Super adapt to a variety of roofing tile products of multi-shape, multi-volume, flexible, high quality and efficient production.

2. Assembled nine linked-function steps in one, the line set achieves through the after-extrusion process to the before-drying process the whole process automatic production without man-made errors. (Nine linked function stages 1Roughly-cutting stage, 2Applying mould release stage, 3Rough-tile transferring stag, 4Rough-tile feeding in stage, 5Green-tile pressing stage, 6Green-tile feeding out stag, 7Spraying mould release stage, 8Tile-shape mending stage, 9Green-tile standing stage)

3. The unique patented technology of reciprocating up & down formation mechanism, much easy to mount & adjust the molds, and accurately control the molding pressure with obvious advantages in mold use & maintenance, and smooth running of stably & reliably.
