Cat5e ROHS PVC Lan Cable Connection Diagram

Name: Cat5e ROHS PVC Lan Cable Connection Diagram
Brand: Canton RPC
SKU: 104724387
Availability: InStock

Cat5e ROHS PVC Lan Cable Connection Diagram thumbnail-1

Cat5e ROHS PVC Lan Cable Connection Diagram photo-1

US$ 57 - 66 MOQ: 50 Boxes

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Canton RPC

Model Number:

cat5e

Contact Supplier Request Quote Chat Now

Foshan Rpc Cable Mfg.

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou/Shenzhen/Foshan

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Canton RPC

Model Number cat5e

Type Cat 5e

Number of Conductors 8

Specifications

cat5e ROHS PVC lan cable connection diagram
Conductor: 99.99% bare copper
Insulation: HDPE
Reference Standard: ISO/IEC 11801

cat5e ROHS PVC lan cable connection diagram

1.Product display

-------------------------------------------------------------------------------------------

2.Mechanical Characteristics

Maximum Pulling Force:50 N

Minimum Bending Radius :45 MM

Nominal Weight:40 KG/KM

Operating Temperature: -15Deg C ~ +70 Deg C

Installation Temperature: +5 Deg C ~ +40 Deg C

Flammability Grade: CMX, CM, CMG, CMR

Pairs: 4

Pair1: Orange/White Orange
Pair2: Blue/ White Blue
Pair3: Green/ White Green
Pair4: Brown/White Brown

Sectional view:

-----------------------------------------------------------------------------------------------------

3. Related product display

cat6 sftp lan cable

-----------------------------------------------------------------------------------------------------------

4.Application

1.Computer Network Cabling Project

2.Broadband Network Communication

--------------------------------------------------------------------------------------------------------------

5.Electrical characteristics: ( at 20°C)

Frequency(MHz)	Impedance(ohm)	RL(dB)	Attenuation(dB/100m)	Next(dB)	Next Power Sum(dB)	ELFEXT(dB)	PSELFEXT(dB)
1.0	100±15	20.0	2.0	62.3~65.3	62.3~62.3	61.0~63.8	61.0~60.8
4.0	100±15	23.0	4.1	53.0~56.3	53.0~53.3	49.0~51.8	49.0~48.8
10.0	100±15	25.0	6.5	47.0~50.3	47.0~47.3	41.0~43.8	41.0~40.8
16.0	100±15	25.0	8.2	44.0~47.2	44.0~44.2	37.0~39.7	37.0~36.7
20.0	100±15	25.0	9.2	43.0~45.8	43.0~42.8	35.0~37.8	35.0~34.8
31.25	100±15	23.6	11.7	40.0~42.9	40.0~39.9	31.0~33.9	31.0~30.8
62.50	100±15	21.5	17.0	35.0~38.4	35.0~35.4	25.1~27.8	25.1~24.9
100.0	100±15	20.1	22.0	32.0~35.3	32.0~32.3	21.0~23.8	21.0~20.8

------------------------------------------------------------------------------------------------------------------

6.Test report

----------------------------------------------------------------------------------------------------------------

7.packing process

first put lan cable into a plastic roller

then into a box

↓

finally wrap the box

↓

---------------------------------------------------------------------------------------------------------------------------------------------------------------------------

pany view

Do you know our producing concept?

We promote the concept of green environmental protection, we produced the jumper wire which is low smoke zero halogen and environmental .

Meanwhile,we follow the principle of human base,

quality first, keep iproving, competitive price satisfactory service ,cost reduction, well effiency, on time delivery.

------------------------------------------------------------------------------------------------------------------

Looking forward to your inquiry and cooperation

We will reply as soon as possible
