Specifications
pass fluke test bare copper cat5e utp network cable connectionsConductor: 99.99% bare copper
insulation: HDPE
pass fluke test bare copper cat5e utp network cable connections
1.Product display
-------------------------------------------------------------------------------------------
2.Mechanical Characteristics
Maximum Pulling Force:50 N
Minimum Bending Radius :45 MM
Nominal Weight:40 KG/KM
Operating Temperature: -15Deg C ~ +70 Deg C
Installation Temperature: +5 Deg C ~ +40 Deg C
Flammability Grade: CMX, CM, CMG, CMR
Pairs: 4
Pair1: Orange/White Orange
Pair2: Blue/ White Blue
Pair3: Green/ White Green
Pair4: Brown/White Brown
Sectional view:
-----------------------------------------------------------------------------------------------------
3. Related product display
cat6 sftp lan cable
-----------------------------------------------------------------------------------------------------------
4.Application
1.Computer Network Cabling Project
2.Broadband Network Communication
--------------------------------------------------------------------------------------------------------------
5.Electrical characteristics: ( at 20°C)
Frequency(MHz) |
Impedance(ohm) |
RL(dB) |
Attenuation(dB/100m) |
Next(dB) |
Next Power Sum(dB) |
ELFEXT(dB) |
PSELFEXT(dB) |
1.0 |
100±15 |
20.0 |
2.0 |
62.3~65.3 |
62.3~62.3 |
61.0~63.8 |
61.0~60.8 |
4.0 |
100±15 |
23.0 |
4.1 |
53.0~56.3 |
53.0~53.3 |
49.0~51.8 |
49.0~48.8 |
10.0 |
100±15 |
25.0 |
6.5 |
47.0~50.3 |
47.0~47.3 |
41.0~43.8 |
41.0~40.8 |
16.0 |
100±15 |
25.0 |
8.2 |
44.0~47.2 |
44.0~44.2 |
37.0~39.7 |
37.0~36.7 |
20.0 |
100±15 |
25.0 |
9.2 |
43.0~45.8 |
43.0~42.8 |
35.0~37.8 |
35.0~34.8 |
31.25 |
100±15 |
23.6 |
11.7 |
40.0~42.9 |
40.0~39.9 |
31.0~33.9 |
31.0~30.8 |
62.50 |
100±15 |
21.5 |
17.0 |
35.0~38.4 |
35.0~35.4 |
25.1~27.8 |
25.1~24.9 |
100.0 |
100±15 |
20.1 |
22.0 |
32.0~35.3 |
32.0~32.3 |
21.0~23.8 |
21.0~20.8 |
------------------------------------------------------------------------------------------------------------------
6.Test report
----------------------------------------------------------------------------------------------------------------
7.packing process
first put lan cable into a plastic roller
then into a box
↓
finally wrap the box
↓
---------------------------------------------------------------------------------------------------------------------------------------------------------------------------
pany view
Do you know our producing concept?
We promote the concept of green environmental protection, we produced the jumper wire which is low smoke zero halogen and environmental .
Meanwhile,we follow the principle of human base,
quality first, keep iproving, competitive price satisfactory service ,cost reduction, well effiency, on time delivery.
------------------------------------------------------------------------------------------------------------------
Looking forward to your inquiry and cooperation
We will reply as soon as possible
