Help CenterSingle Phase Tamper Protection LCD Display Energy Meter
Related Products
-
Single Phase Tamper Proof LCD Display Energy MeterUS$ 6.50 - 7.50MOQ: 1000 Pieces -
Low Cost Single Phase LCD Display Energy MeterUS$ 6.50 - 7.50MOQ: 1000 Pieces
-
Low Cost Single Phase LCD Display Electricity MeterUS$ 6.50 - 7.50MOQ: 1000 Pieces
-
Single Phase Register Display Electricity Energy MeterUS$ 4.50 - 6.00MOQ: 1000 Pieces
-
Single Phase Register Display Energy MeterUS$ 4.50 - 6.00MOQ: 1000 Pieces
Main Features
- Energy Measurement
Total and time-sharing forward active & reactive energy measurement
Total and time-sharing reverse active & reactive energy measurement
Save last one to sixteen months energy data
- TOU
4tariffs, Measures active energies in TOU or step tariffs with standard DLMS support
- Tamper detection
With event recording function (including cover-opening event, tamper event and power failure event)
- Optical port interface
Communication standards ,Support IEC62056-21 protocol
- RS-485 serial interface
Support IEC62056(DLMS/COSEM) protocol
- LCD display
Number of digits value field Up to 7
Digit size 4x10mm
Technical parameters:
Electrical parameters: | |
Voltage | |
Nominal voltage Un |
230V |
Extended operating voltage range |
80%~115%Un |
Limited voltage |
70%~120%Un |
Frequency |
|
Nominal frequency fn |
60Hz |
tolerance |
5% |
Current |
|
Basic current(Ib) |
10A |
Maximum current(Imax) |
100A |
Starting current(Ist) |
30mA |
Active energy constant |
1000imp/kWh |
Measurement Accuracy |
|
Active energy to IEC62053_21 |
Class1.0 |
Reactive energy to IEC62053_23 |
Class2.0 |
Power Consumption |
|
Power consumption in Voltage circuit |
<2W <8VA |
Power consumption in current circuit |
<1VA |
Temperature range |
|
Operation meter |
25℃ to+70℃ |
Storage |
40℃ to+85℃ |
| |
Insulation strength | |
AC Insulation strength |
4kV at 50Hz during 1min |
Impulse voltage 1.2/50 μs mains connections |
8kV |
|
|
Electro Magnetic Compatibility | |
Electrostatic discharges |
|
Contact discharge |
8kV |
Air discharge |
16kV |
Electromagnetic RFfields |
|
27MHz to 500MHz typical |
10V/m |
100kHz to 1GHz typical |
30V/m |
Fast transient burst test |
4kV |
|
|
Mechanical requirements |
|
Meter shell Protection Rate |
IP54 |
Protection |
classII |
