Full electric Self-Propelled Scissor Lifts
Scissor Lifts
Roll-out extension platform provide more workspace
1 Neatly folding guardrails make it easy to maneuver through doorways, into elevators and throughout other height-restricted areas
2 Four models are available with the maximum working height at 8m to 12m
3 Zero-turn radius and compact design provide access in and around confined work areas
4 25% gradeablility when driving on slopes
5 Swing-out tray for easy maintenance access
6 On-board diagnostice help operators troubleshoot on the fly and make adjustments in the field to maximize uptime
Self-Propelled Scissor Lifts
| Model | FSJY0608 | FSJY0810 | FSJY1012 | |
| Maximum working height | mm | 8000 | 10000 | 12000 |
| Maximum platform height | mm | 6000 | 8000 | 10000 |
| Folding maximum height(guardrail unfolding) | mm | 2150 | 2275 | 2400 |
| Folding maximum height(guardrail removed) | mm | 1190 | 1315 | 1440 |
| Overall Length | mm | 2400 | 2400 | 2400 |
| Overall Width | mm | 1150 | 1150 | 1150 |
| Platform Size | mm | 2270×1150 | 2270×1150 | 2270×1150 |
| Platform extend size | mm | 900 | 900 | 900 |
| Minimumground clearance(folding) | mm | 110 | 110 | 110 |
| Minimumground clearance(rising) | mm | 20 | 20 | 20 |
| Wheelbase | mm | 1850 | 1850 | 1850 |
| Minimum turn radius(inner wheel) | mm | 0 | 0 | 0 |
| Minimum turn radius(outer wheel) | mm | 2100 | 2100 | 2100 |
| Power source | v/kw | 24/3 | 24/3 | 24/3 |
| Running speed(folding) | km/h | 4 | 4 | 4 |
| Running speed(rising) | km/h | 0.8 | 0.8 | 0.8 |
| Rising/falling speed | sec | 40/50 | 40/50 | 70/80 |
| Battery | V/Ah | 4×6/210 | 4×6/210 | 4×6/210 |
| Charger | V/A | 24/25 | 24/25 | 24/25 |
| Maximum climbing ability | % | 20 | 20 | 20 |
| Maximum working allowable angle | / | 2-3° | 2-3° | 2-3° |
| Way of control | / | Electro-hydraulic proportion control | ||
| Driver | / | Double front-wheel | ||
| Hydraulic drive | / | Double rear-wheel | ||
| Wheel size(stuffed&no mark) | / | Φ381×127 | Φ381×127 | Φ381×127 |
| Lifting capacity | kg | 300 | 300 | 300 |
| Whole weight | kg | 1900 | 2100 | 2300 |
Self-Propelled Scissor Lifts
Standard equipment
Proportional controls
Drivable at full height
Non marking tyre
Automatic brakes system
Emergency stop button
Emergency lowering system
Onboard diagnostic system
Tilt sensor with alarm
Horn
Hour meter
Safety brackets
Forklift pockets
Folding guardrails
Extended platform
Full electric Self-Propelled Scissor Lifts
Charger protection
Flashing beacon
Self-Propelled Scissor Lifts
Self-Propelled Scissor Lifts
....
