Sugarcoat machine BGc-400
Descriptions
The unit is consisted by main motor,air inlet,spraying supplying system.Stepless variable-speed is control by frepuency control driving ,air inlet with three grade of purifying,air outlet with filtering ,spray use gun of high air fog.Temperature of air tablets and liquid is adjusted and ating process space.The unit is easy to cleaned and to be maintained,cost is low.
Scope of application
The closed coating machine is used for coating sugar,organic film,water soluble film,slow and controlled release film on traditional Cjinese and Western tables and pills(including micro pills,small pills,water-bindered pills,drip pills and granulated pills)and conforms to the requirement of GMP.It is a improxing product first independently researched and developed in China by our company which depend on water chestnut shape coating machine.
Technical parameters
Name Model |
BGc-400 |
BGc-800 |
BGc-1000 |
BGc-1250 |
Diameter of coating pot |
400 |
800 |
1000 |
1250 |
Working capacity(kg/time) |
3--5 |
30-50 |
50-70 |
80-150 |
Range of air temp () |
20-110 |
20-110 |
20-110 |
20-110 |
Motor speed (r/min) |
1.5-46 |
1.5-40 |
1.5-32 |
1.5-28 |
Power of the main motor (kw) |
0.55 |
1.1 |
1.5 |
2.2 |
Power of air inlet (kw) |
0.04 |
0.75 |
0.75 |
0.75 |
Power of heated (kw) |
0.6 |
3.0 |
3.5 |
3.5 |
Power of air outlet (kw) |
0.1 |
1.5 |
1.5 |
2.2 |
Lighting (w) |
18 |
18 |
20 |
20 |
Dimensions(L x W x H)(mm) |
800 X 800 |
1000 X 1000 |
1200 X 1200 |
1350 X 1350 |
