SUAGRCOATING MACHINE BY200,BY300,BY400Descriptions
The machine is mainly used in the coating ,glazing ,granulation of the pharmacy trade ,it can also be used to ball object mould shape make in food and chemical industry trade.
Features
In order to improve level and property of coating equipment to satisfy the needs of user.Our company design,manufacture install coater as GMP request based on original one.Inner pot with diversion board and automatic spray liquid system .It can adjust temperature and speed.The machine has advantage of not pollution.easy to clean and to maintain,low cost.
This coating pan is made of stainless steel , the complete machine transmission is steady ,performance is reliable .it is convenient to wash and maintain ,thermal efficiency is high ,it can produce the technological requirement and regulate coating in one pot of angles at the same time, and is easy to use .it is the ideal equipment in the trade as medicine ,food ,chemical industries ,etc.
This machine can increase the step less speed regulation according to users enquiry ,wrap up such systems as the outer cover and gushing out liquid ,hot wind ,dust removal ,etc.
Technicl parameters
Name Model |
BY200 |
BY300 |
BY400 |
Diameter(min) |
200 |
300 |
400 |
Speed(rrain) |
46 |
46 |
46 |
Power of main motor(kw) |
0.25 |
0.37 |
0.55 |
Power of heat wire(kw) |
Hair-dryer |
500 |
500 |
Power of blower(kw) |
250--450 |
40 |
40 |
Working capacity(kgtime) |
1 |
2 |
5 |
Weight(kg) |
60 |
65 |
70 |
Dimensions(L x W X H)(mm) |
350 X 400 |
485 X 585 |
485 X 585 |
Power of outer heated (kw) |
|
500 |
500 |
