Wireless NVR Kit Specification(M1010NW4)
|
Key Features: up to 60m with 3 walls | ||
|
|
Item specifics 4 pcs 720P/1080P cameras 1pcs 4ch 1080P NVR 1pcs RJ45 network cable 1pcs12V 3A+4pcs 12V 1A power supply English User Manual CD(CMS,mobile app,manual), Mouse |
|
| Wireless NVR Specification | ||
| Model | M1010NW4 | |
| Operating System | Embedded Linux OS | |
| AV(audio/video)input | Network Video | 4CH |
| Network video input broadbank | 20Mbps | |
| AUdio Bitrate | 64Kbps | |
| AV (audio/video) output | HDMI input | 1ch,resolution:1024x768,1366x768, 1440x900,1920x1080p |
| LCD output | 1ch,10.1'' resolution:1024x800 | |
| AV CODEC Specification | Video Resolution | D1/720P/1080P |
| synch-playback | 4CH | |
| Video Control | Video/Capture mode | Maual,Time,Motion,Alarm |
| Playback mode | Real time,Routine,Event | |
| Backup | USB backup | |
| Alarm | Alarm Input | 4ch (optional) |
| Alarm Output | 1ch (optional) | |
| Hard Disk | Type | 1*SATA interface |
| Max Capacity | 4 TB at most for each | |
| External Interface | Network Interface |
1 adaptable RJ45 10M/100M, 1 WIFI interface |
| USB Interface | 2 USB 2.0 | |
| Protocol |
UPnP (play&plug)/SMTP (email survice)/PPPoE (dial-up) |
|
| Network Control | ||
| Others | Power Supply | DC12V3A |
| Power Consumption (W) | ≤10W(Without HDD) | |
| Operate Temperature (°C) | -10℃~+55℃ | |
| Working Humidity (%) RH | 10%~90% | |
| Size | 280mm(W)×225mm(V)×45mm(H) | |
| Weight(excluding HDD) | ≤1Kg | |
| IPC Specification | ||
| Technical Parameters | Model | C1109DN2-W |
| Sensor | 1/4” Progressive Scan Sensor | |
| Signal System | PAL/NTSC | |
| Resolution | 1280 x 720 | |
| Minimum illumination | Color: 0.1 Lux; B/W: 0.01 Lux | |
| Shutter | 1/25s to 1/25,000s | |
| Lens | 4mm | |
| OSD | Date Time & Title | |
| White Balance | Auto | |
| Day&Night | Auto / Color / BW | |
| 3D-DNR | Auto | |
| Mirror/Flip | On / Off | |
| Frame Specification | Three Streaming at the Same Time: H.264 1280x720@30fps or below H.264 640x480@30fps or below |
|
| S/N | > 39.1 Db | |
| Interface | RJ45 / WIFI 802.11b/g/n | |
| General Specification | Anti-thunder Level | Standard IEC61000-4-5 |
| Working Temperature/Humidity | -10℃ to +50℃ / 30% to 80% RH | |
| Working Temperature/Humidity | -20℃ to +60℃ / 20% to 90% RH | |
| Power Input | DC12V-1A | |
| Power consumption | ≤6W | |
| Size | 205(L)×70(W)×55 (H)mm | |
| Weight | 500g | |
| Level of Protection | IP66 | |
Sample Availability & Policy :
could you let us know your quantity? price can be negotiated based on Your quantity.
and sample is evaluated before bulk order production.
Guarantees/Warranties/Terms and Conditions :
We guarantee each shipment before shipping, it will be strictly inspected by our own inspector or customer's appointed inspector. According to different products or different composed parts, we provided one to two years quality guarantee after shipment.
After Sales Service :
During valid quality guarantee period, we provide spare parts or technical support to fix or upgrade the software. If the problem can't be resolved by you, please return the defective to our Hong Kong provided address and we fix it for you.
QC/Technical Support :
Our quality control and technical department is mainly composed by 10 to 19 professional workers. It includes three parts such as raw material, production is going on and final products.
Add:Rm. 1212, Bldg. 2, Henghe Center, No. 313, Renmin East Road, Xiangzhou Dist. ,Zhuhai City,Guangdong,China.
More information you may be interested in:
Q:How can we get samples from you?
A:Clients select the interested items, including product name and quantity
B: We need your address for checking air shipping cost.<-2Fspan>
C: We make Sample PI for you
D: You make the transfer
E: Samples will be sent out once we get the transfer, and we'll provide the UPS Tracking number.
Q: What’s the delivery date?
A: If for our brand products, we’ll ship the goods within 3-5 working days. If for OEM products, it’s about 10-15days, depends on the quality packaging.
Q: How can we pay you?
A: We accept Western Union and T/T,you can select which type is most suitable for you.
