Specifications
100w Chinese wind generators/ wind energy generatorRated power:100W
Factory direct sales
low noise
100w Chinese wind generators/ wind energy generator
Feature:
1. Large power, small volume, low weight, high efficiency
2. Carbon fiber blades, high efficiency of anti-wind ability
3. Blades with the ability of automatically stall protection under strong wind
specification:
<
| Model | Z-50W | Z-100W |
| Product Name: | Hyacinth wind generator prices 50w | |
| Rated Power | 50W | 100W |
| Rated DC Voltage | DC12V/24V | DC12V/24V |
| Rated Current | 4.4A/2.2A | 8.8A/4.4A |
| Rated Rotating Rate | 1050r/m | 860r/m |
| Max Power | 65W | 115W |
| Start-up Wind Speed | 3m/s | 3m/s |
| Cut-in Wind Speed | 3.5m/s | 3.5m/s |
| Cut-out Wind Speed | 15m/s | 15m/s |
| Security Wind Speed | 45m/s | 45m/s |
| Rated Wind Speed | 12m/s | 12m/s |
| Egine | Three-phase Permanent Generator | |
| Rotor Diameter | 1050mm | |
| Number of Blade | 3pieces | |
| Blade Material | Carbon Fiber Reinforced Plastics | |
| Output Line Anti-winding Device | Overall Three-phase Commutator | |
| Wind Protection | Tip Stall Protection +Turned Protection+Electromagnetic Protection | |
| Life Span | 10 years | |
| Surface Protection | Galvanization Plastic Coating | |
| Working Temperature | -40°C-70°C | |
| Packing Material | Carton+Foam | |
| Package Size | 615*260*210mm | 615*260*210mm |
| Gross Weight | 3.6kg | 4kg |
Product Show:
Engineering Example:
Certification of hybrid solar wind power generator :
Payment & shipment:
why choose us:
1.Strong production ablility:-Monthly output is over 10000pcs.
2.Customized packing and customer's logo are accepted.
3.Sample order is welcome and it can be returned in your bulk order.
4,Quality control before shipping,two year warranty.
5,Certifications-CE/ROHS/Reach,ISO9001:2004
6.Professional factory directly sale all over the wrold. we can produce various wind generator according to customer's requirements.
7,Faster delivery: 3~7 days.
