Specifications
small wind turbine motor 800w1.2 years warranty
2.MOQ 1set
2014 new small wind turbine motor 800w 300w 400w 600w 1000w
Feature:
1. Large power, small volume, low weight, high efficiency
2. Carbon fiber blades, high efficiency of anti-wind ability
3. Blades with the ability of automatically stall protection under strong wind
specification:
| Model | Z-800W |
| Product Name | Dolphin small wind turbine |
| Rated Power | 800W |
| Rated DC Voltage | DC12V/24V/48v |
| Rated Current | 66A/33A/16A |
| Rated Rotating Rate | 620r/m |
| Max Power | 900W |
| Start-up Wind Speed | 3m/s |
| Cut-in Wind Speed | 3.5m/s |
| Cut-out Wind Speed | 15m/s |
| Security Wind Speed | 45m/s |
| Rated Wind Speed | 12m/s |
| Egine | Three-phase Permanent Generator |
| Rotor Diameter | 1870mm |
| Number of Blade | 5 pieces |
| Blade Material | Carbon Fiber Reinforced Plastics |
| Output Line Anti-winding Device | Overall Three-phase Commutator |
| Wind Protection | Tip Stall Protection +Turned Protection+Electromagnetic Protection |
| Life Span | 10 years |
| Surface Protection | Aluminium Oxide+Plastic Coating |
| Working Temperature | -40°C-70°C |
| Packing Material | Carton+Foam |
| Package Size | 830*530*460mm |
| Gross Weight | 28 kg |
Product Show:
Engineering Example:
Certification of wind generator:
Payment & shipment:
why choose us:
1.Strong production ablility:-Monthly output is over 10000pcs.
2.Customized packing and customer's logo are accepted.
3.Sample order is welcome and it can be returned in your bulk order.
4,Quality control before shipping,two year warranty.
5,Certifications-CE/ROHS/Reach,ISO9001:2004
6.Professional factory directly sale all over the wrold. we can produce various wind generator according to customer's requirements.
7,Faster delivery: 3~7 days.
