Specifications
1best quality best price2certificate CE RoHS and ISO
3small volume,low weight, large output
1. Streamlined design,simple structure,running stably,power supply for city lamps,monitoring and home use.
2. Small size and flexible,lively colors,beautiful curve,low noise and harmony with environment.
Wind generator part |
Model |
Z-600W |
Name |
Hyacinth |
|
Rated power |
600W |
|
Rated DC voltag |
DC 24V |
|
Rated current |
25A |
|
Rated speed |
640r/m |
|
Max power |
680W |
|
Number of blade |
5 pcs |
|
Starting wind speed |
2.5m/s |
|
Cut-in wind speed |
3m/s |
|
Cut-out wind speed |
15m/s |
|
Security wind speed |
45m/s |
|
Rated wind speed |
12m/s |
|
Engine |
Three-phase permanent magnel generator |
|
Rotor diameter |
1850mm |
|
Blade material |
Carbon fiber reinforced plastics |
|
Output line anti-winding device |
Overall three-phase commutator |
|
Over-speed wind protection |
Tip stall protection + turned protection + Electromagnetic brake |
|
Life span |
15 years |
|
Equipment surface protection |
Aluminum oxide+plastic coating |
|
Working temperature |
-40°C-70°C |
|
|
N.W. |
19.5kg |
Packing material |
Carton box and foam material |
|
| packing dimension | 1110*580*240mm |
|
G.W. |
23Kg |
