Specifications
Low speed permanent magnet generatorLow starting torque
High generating efficiency
Glassfibre high efficiency blades
Model:Dolphin 300W
Product Characteristics:
1. Large power, low volume, low weight, high efficiency
2. Carbon fiber blades, high efficiency of anti-wind ability
3. Blades with the ability of automatically stall protection under strong wind
Product Specification:
Model |
TH-300A |
TH-300B (low start up wind speed ) |
Name |
Dolphin |
Dolphin |
Rated power |
300W |
300w |
Rated DC voltage |
DC 12V/24V |
DC12V/24V |
Rated current |
25A/12.5A |
25A/12.5A |
Rated speed |
1850r/m |
1850r/m |
Max power |
380W |
380w |
Number of blade |
3 pcs |
3pcs |
Starting wind speed |
2.5m/s |
1.5m/s |
Cut-in wind speed |
3.5m/s |
2.5m/s |
Cut-out wind speed |
18m/s |
18m/s |
Security wind speed |
45m/s |
45m/s |
Rated wind speed |
12.5m/s |
12.5m/s |
Engine |
Three-phase permanent magnel generator |
|
Rotor diameter |
1250mm |
1250mm |
Blade material |
Carbon fiber |
Carbon fiber |
Output line anti-winding device |
Overall three-phase commutator |
|
Over-speed wind protection |
Tip stall protection + turned protection + Electromagnetic brake |
|
Life span |
15 years |
15 years |
Equipment surface protection |
Aluminum oxide + plastic coating |
Aluminum oxide+plastic coating |
Working temperature |
-45C-70C |
-45C-70C |
N.W. |
5.85kg |
5.85kg |
Packing material |
Carton box and foam material |
Carton box and foam material |
packing dimension |
720*390*210mm |
720*390*210mm |
G.W. |
7.5kg |
7.5KG |
Special offer products
Model |
P-300W |
Starting wind speed |
2.0m/s |
Cut-in wind speed |
2.5m/s |
Rated wind speed |
12m/s |
Rated DC voltage |
12/24V |
Rated output AC voltage |
220V/50Hz(110v/60Hz) |
Over-speed protection |
Electromagnetic torque control |
Engin |
Permanent magnetism synchronization generator |
Rated speed |
810 |
Wind energy utilization rate |
0.41 |
Colour |
Various |
N.W. |
5.8kg |
Blade material |
Extra-strong and tenacious engineering plastics |
Rotor diameter |
1250mm |
Rotor length |
1350mm |
Rated power |
300W |
Packing material |
Carton box and foam material |
packing dimension |
650*400*320mm |
G.W. |
7.5kg |
We are specialized in producing small wind turbines,wind & solar hybrid system for street lights,Monitoring system.We can prinit any colors of blade,cap according to your request.welcome to visit us.
