Specifications
1.Weight 2.6kg and protable2.CE RoHS
3.Low nosie
Wholesales 100w portable and small wind turbine generator windmill 12v 24v AC
+100w wind & solar hybrid controller
Product Characteristics:
1.Portable, using ultra-light composite materials and engineering plastics, the weight of 2500g,
2.installation or disassembly in 3 minutes and a small space occupied
3.The machine head can be arbitrary rotated with anti-winding devices
4.Large capacity, to be Wind-Solar Hybrid power supply system with solar cell
5.Providing 0.6-1.5 degrees power in 24 hours meet the need of portable computers,Instrument, mobile phones and lighting
Model |
100W |
Rated power |
100W |
Max power |
115w |
Starting wind speed |
2.5m/s |
Cut-in wind speed |
3.0m/s |
Rated wind speed |
12.5m/s |
Rated DC voltage |
12/24V |
Rate totating speed |
1050r/m |
Over-speed protection |
Electromagnetic torque control |
Rated speed |
12.5m/s |
Color |
White |
N.W. |
3.5kg |
Rotor diameter |
1050mm |
Wind protection |
Tip stall protection |
Life span |
15 years |
Packing material |
Carton box and foam material |
packing dimension |
615*260*210mm |
G.W. |
4.5kg |
Wind solar hybrid controller
Wind turbine power |
400 W 12V/24V |
Solar rated power |
150W/12V 300W/24V |
Rated Battery Voltage |
12 V/24V |
Wind turbine power Max. |
600 W |
Wind turbine current Max. |
50 A |
Over-charge Voltage |
14.5V/12V; X2/24V |
Over-discharge Voltage |
10.8 V/12V; X2/24V |
Method of control |
PWM |
Free-load lost power |
less than 6 mA |
Voltage lost on charging |
less than 0.26V |
Voltage lost on discharge |
less than 0.15V |
Display |
* Red-LED show battery voltage status * Night-LED show device DC power output * Charge-LED show system charging status |
Protection Mode |
Solar cells reverse charging, solar cells anti-reverse connection, battery over-charging, battery over-discharge, battery anti-reverse connection, over-load, Load anti-reverse connection, wind-turbine current limited, wind-turbine rotation limited, manual brake switch equipped. |
ambient temperature |
-25 - +55 |
humidity |
<85% RH without condensation |
Dimension |
190mm x 150mm x 65mm |
Weight (kgs) |
1.2 kg |
Above is our standard model designed. Welcome your special requirement as necessary, we would like to do re-design and configuration adjust for your expectation accordingly . | |
Factory
Wind tunnel
Simulate common wind to see how wind generator how to work
Production workshop
Warehouse
Sample order:
MOQ:1 Piece Order:If you quanlity more than 20 pieces,you will enjoy discount.
Warranty time:2 years
Payment:
Sample payment must be paid within 3 days,
Order:30% deposit,70% should be paid before shipment
Kindly Reminding
Before purchasing our products,please tell us what is your application,power requirements,we will offer you favorable and effective configuration selections. Such as the voltage:DC or AC ? 12V or 24V?
The above price is not including : Pole inverter and battery . if you need them also, Please contact us with email or trade manager.
