RF Coaxial Mini SMA Connector With Female S/T Jack and 2-hole Panel SQ Flange for Panel Mount Connector
US$ 0.1 - 0.6
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SH-Link
Model Number:
SMA-50KF-1
Payment & Shipping
Payment Methods:
Port of Shipment:
Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
RF SMA Bulkhead Panel Mount ConnectorUS$ 0.1 - 0.9MOQ: 100 Pieces -
Coaxial Type RF Cable IPX1.13 U.fl to SMA ConnectorUS$ 0.1 - 0.9MOQ: 100 Pieces
-
Waterproof Sma ConnectorUS$ 0.1 - 0.9MOQ: 100 Pieces
-
RP SMA Jack Rg174 Cable Sma Wire Crimp ConnectorsUS$ 0.1 - 0.9MOQ: 100 Pieces
-
High Quality Sma Double Plug Adapter,bulkhead SmaUS$ 0.1 - 0.9MOQ: 100 Pieces
Place of Origin
Guangdong, China
Brand Name
SH-Link
Model Number
SMA-50KF-1
Type
SMA
Application
RF
Gender
Female
1.sma,female with flange rf connector,50Ohm
2.good price,reliable quality,quick delivery time
3.welcome to place a trial order
Type SMA is one kind of RF coaxial connectors that is widely applied, with small-sized thread coupling, characteristic impedance is fifty Ohm. The characteristic of connectors is in wide frequency range, excellent performance, high reliability. They are used in connection with RF cable or micro-strip line in RF circuit of the WLAN system, controlled program, microwave equipment and the digital communication system. The frequency can be up to 18GHz by using semi-rigid or semi-flex cable.
MAJOR TECHNICAL CHARACTERISTICS
| Temperature range | -55—+155℃(PE Cable -40—+85℃) | |
| Vibration | 98m/S²(10-2000Hz)10g | |
| Impedance | 50Ω | |
| Frequency range | DC-12.4GHz(Semi-Rigled Cable DC-18GHz) | |
| Working voltage | 335V r.m.s at sea level | |
| Withstanding voltage | 1000V r.m.s at sea level | |
| Contact resistance | ||
| Center contact | ≤3mΩ | |
| Outer contact | ≤2.5mΩ | |
| Insulation resistance | ≥5000MΩ | |
| Center conductor retention force | ≥0.28N | |
| Coupling nut retention force | ≥180N | |
| Insertion loss | ≤0.15dB/6GHz | |
| Voltage Standing Wave Ratio | ||
| Straight | ≤1.10+0.02f | |
| ≤1.07+0.018f | ||
| Right angle | ≤1.20+0.03f | |
| ≤1.17+0.02f | ||
| Durability(mating) | ≥500times(Cycles) | |
