Warm White SMD 12 Volt Automotive Led 1156 Bulbs for Car

Warm White SMD 12 Volt Automotive Led 1156 Bulbs for Car thumbnail-1
Warm White SMD 12 Volt Automotive Led 1156 Bulbs for Car photo-1
US$ 2 - 2.5 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Type:
Interior Lamp
Voltage:
Other, 10-30V DC 12V AC/DC
Lamp Type:
LED
Contact Supplier Request Quote Chat Now
Shenzhen Gapray Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Interior Lamp
Voltage Other, 10-30V DC 12V AC/DC
Lamp Type LED
Certification CE RoHS, CE RoHS
Car Make all cars
Place of Origin Guangdong, China
Brand Name Gapray
Model Number 15SC-18DCW-30D
Warranty 24 Months

Warm white SMD 12 Volt  automotive led 1156 bulbs for car

Product Code Base Voltage Current Watts (Typ.) LED Q'ty LED Encapsu-lation CCT(K)/ Color Lumens (Typ.) MOQ(PCS)
15SC-18DCW-30D BA15s 10-30VDC 195mA 2.4 18 SMD2835 6450K 323 100
15SC-18DWW-30D BA15s 10-30VDC 195mA 2.4 18 SMD2835 2777K 286 100
Y15C-18DCW-30D BAY15d 10-30VDC 195mA 2.4 18 SMD2835 6450K 323 100
Y15C-18DWW-30D BAY15d 10-30VDC 195mA 2.4 18 SMD2835 2777K 286 100
15DC-18DCW-30D BA15d 10-30VDC 195mA 2.4 18 SMD2835 6450K 323 100
15DC-18DWW-30D BA15d 10-30VDC 195mA 2.4 18 SMD2835 2777K 286 100







Product Description:

The automotive led 1156 bulbs is ideal for replacing your existing incandescent or halogen bayonet lights, has a light output equivalent to a 25W incandescent bulb. they are used for a wide variety of applications on most RVs, automotive, boat and other fitting with bayonet base. and is ideal for both 12 Volt & 24 Volt systems.



It combines18 surface mount (SMD) LEDs arrayed in 6 planes for 360 visibility. Proprietary PWM Constant-Current chipset results in high performance across the entire 8-30VDC range. The tower types provide light in all directions and makes it ideal for wall lights,interior light, ceiling lights and large fittings which use double-contact 1156 base.



Beam Angle: 360°
Color Temperature: 2850-3250K,6300-7000K
Base Type: 1156 1157 1142
Dimensions: 18mm x 46mm (incl. base)
Lifetime 50,000 hours
Warranty: 2-Years
CRI: >80
Operating Temperature:  -30~+60 °C
Warranty: 2 years
Colours: White, Green, Blue, Amber, Red.
Certification: CE RoHS Compliant
Dimmable: non-dimmable
Polarity Sensitive: Non-polar
IP Rating: Non-Weatherproof

 Warm white SMD 12 Volt automotive led 1156 bulbs for car     Warm white SMD 12 Volt automotive led 1156 bulbs for car



Features & Benefits:

1. Constant-current drive topology

2. Very low power consumption

3. Over-voltage protection

4. No radiated heat

5. Wide voltage input range

6. Shockproof - ultra-rugged with no filament to burn out or break
7. Lead and mercury free, no UV output

8. Zero RF emission, surface mount device design


Notice:
Replaces Stock Bulb 1076 1142 1176 1376.





certificates:

All automotive led 1156 bulbs products have CE RoHS certification.

 Warm white SMD 12 Volt automotive led 1156 bulbs for car

Warm white SMD 12 Volt automotive led 1156 bulbs for car





Applications:



1. RVs, automotive, Yacht, motor home and etc

2. Hotel, Entertainment place, Household, office light, , home use light, etc.


Warm white SMD 12 Volt automotive led 1156 bulbs for carWarm white SMD 12 Volt automotive led 1156 bulbs for car



Trade Terms:

1 Payment: Western Union or T/T are welcomed.

2 Production lead time for 100-30000pcs:7-15 days

3 Sample of automotive led 1156 bulbs can be delivered in 3days





Our Services:

1) Provide you professional automotive led 1156 bulbs design

2) Warranty 2 years and maintenance free

3) All your inquiry will be reply in 24 hours in our working day

4) Well-trained and experienced staffs to answer all your enquiries in fluent English.

5) OEM&ODM, any your customized lightings we can help you to design and put into product.

6) Distributorship are offers for your unique design and some our current models.
