White Omni Turn Light Type LED 1156 BA15s 7506 P21W Bulb

White Omni Turn Light Type LED 1156 BA15s 7506 P21W Bulb thumbnail-1
White Omni Turn Light Type LED 1156 BA15s 7506 P21W Bulb photo-1
US$ 2.5 - 3 MOQ: 100 Pieces
Key Specifications
Get Latest Price
Type:
Interior Lamp
Voltage:
Other, 12V AC/DC 10-30V DC
Lamp Type:
LED
Contact Supplier Request Quote Chat Now
Shenzhen Gapray Lighting Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Interior Lamp
Voltage Other, 12V AC/DC 10-30V DC
Lamp Type LED
Certification CE RoHS, CE RoHS
Car Make all cars or boats
Place of Origin Guangdong, China
Brand Name Gapray
Model Number 15SC-18ACW-30D
Warranty 2 Years

360 degree Turn Light Type LED 1156 BA15s 7506 P21W Bulb

Product Code Base Voltage Current Watts (Typ.) LED Q'ty LED Encapsu-lation CCT(K)/ Color Lumens (Typ.) MOQ(PCS)
15SC-18ACW-30D BA15s 10-30VDC 185mA 2.4 18 SMD5050 6358K 312 100
15SC-18AWW-30D BA15s 10-30VDC 185mA 2.4 18 SMD5050 3034K 304 100
Y15C-18ACW-30D BAY15d 10-30VDC 185mA 2.4 18 SMD5050 6358K 312 100
Y15C-18AWW-30D BAY15d 10-30VDC 185mA 2.4 18 SMD5050 3034K 304 100
15DC-18ACW-30D BA15d 10-30VDC 185mA 2.4 18 SMD5050 6358K 312 100
15DC-18AWW-30D BA15d 10-30VDC 185mA 2.4 18 SMD5050 3034K 304 100





Product Description:

The LED 1156 BA15s 7506 P21W Bulb is ideal for replacing your existing incandescent or halogen bayonet lights, has a light output equivalent to a 25W incandescent bulb. they are used for a wide variety of applications on most RVs, automotive, boat and other fitting with bayonet base. and is ideal for both 12 Volt & 24 Volt systems.



It combines 18 surface mount (SMD) LEDs arrayed in 6 planes for 360 visibility. Proprietary PWM Constant-Current chipset results in high performance across the entire 8-30VDC range. The tower types provide light in all directions and makes it ideal for turn sigal light, interior light, ceiling lights and large fittings which use single-contact 1156 ba15s base.



Beam Angle: 360°
Color Temperature: 2850-3250K,6300-7000K
Base Type: 1156 1157 1142
Dimensions: 18mm x 46mm (incl. base)
Lifetime 50,000 hours
Warranty: 2-Years
CRI: >80
Operating Temperature:  -30~+60 °C
Warranty: 2 years
Colours: White, Green, Blue, Amber, Red.
Certification: CE RoHS Compliant
Dimmable: non-dimmable
Polarity Sensitive: Non-polar
IP Rating: Non-Weatherproof



White omni Turn Light Type LED 1156 BA15s 7506 P21W Bulb             White omni Turn Light Type LED 1156 BA15s 7506 P21W Bulb





Features & Benefits:

1. Constant-current drive topology

2. Very low power consumption

3. Over-voltage protection

4. No radiated heat

5. Wide voltage input range

6. Shockproof - ultra-rugged with no filament to burn out or break
7. Lead and mercury free, no UV output

8. Zero RF emission, surface mount device design


Notice:
Replaces Stock Bulb
1157 (Dual Circuit) = 1016 1034 1076 1077 1130 1154 1158 1493 2057 2357 2397 7528

1156 (Single Circuit) = P21W 1073 1093 1129 1141 1159 1295 1459 1619 1651 1680 7506 7527





certificates:

All LED 1156 BA15s 7506 P21W Bulb have CE RoHS certification White omni Turn Light Type LED 1156 BA15s 7506 P21W Bulb





Applications:

1.Car, Yacht, RVs, Caravan, Boat, and etc

2. Hotel, Entertainment place, Household, shopping malls, office light, , home use light, etc.
White omni Turn Light Type LED 1156 BA15s 7506 P21W Bulb
