SHG1200 workshop HDPE fitting welding machine
Application and features :
> Applied to fabricate PE PP PVDF elbow, tee, cross and Y shape (45° and 60 °) fittings in workshop. Also used to lengthen the injection moulded fitting and make an integrated fitting.
> Integrated structure. Nothing remains but to choose the different special clamps while fabricating different fittings
> Removable PTFE coated heating plate with separate temperature controlling system
> Electric planing tool with safety limit switch enable to start it only when it is locked in the operation position
> Low starting pressure and high reliable seal structure
> Separate two-channel timer records times in soaking and cooling phases.
> Digital pressure meter enables to control pressure accurately
> Linear guide ways are equipped with eating plate, planing tool and dragging plate
The necessary band saw to cut pipe with angel is on sale, please review our website.
The main parameters:
Model |
SHG1200 |
|
Pipe sizes (mm) |
630,710,800,900,1000,1200 |
|
Working ranges Elbow |
0~90° Elbow.tee,cross,45°,60°Wyes(optional parts should be used) |
|
Heating Plate Max. Temp. |
270°C |
|
Temp. deviation in surface (170~250°C) |
<±7°C |
|
Pressure adjustable ranges |
0~16MPa |
|
Working Voltage |
380V 50Hz |
|
Heating plate power |
61.39KW |
|
Planing tool power |
4KW |
|
Hydraulic unit power |
10.5KW |
|
Total power |
75.89KW |
|
Total weight |
18000KG(Exclude optional parts |
|
Packing |
Cases |
11 Plywood Cases |
Volume |
41.93 CBM |
|
Optional parts:
> Special clamps for welding flange stub
> Special clamps for short fitting
