SJC1200 band saw to cut plastic pipe with angle
- 1 Set / Sets per Month
- Shanghai
- T/T
Product Details
Condition: | New | Type: | Hydraulic Cutting Machine | Application: | <=1200mm |
Place of Origin: | Jiangsu, China | Brand Name: | Shengda | Model Number: | SJC1200 |
Rated Power: | 6.25KW | Voltage: | 380V | Power(W): | 7.7KW |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
SJC1200 band saw to cut plastic pipe with angle, plastci pipe cutting machine
Application and features:
> Suitable for cutting pipes according to specified angel and dimension while making an elbow, tee or cross, which lowest the material waste and improve the welding efficiency
> Cutting angle 0~67.5° accurate angle location
> Applied to solid pipes or structured wall pipes made of thermoplastic such as PE and PP, and also other pipe and fittings made of non-metal materials
> Self inspection and stop of the machine in case of saw blade breaks enables to guarantee operator’s safety
> A special designed integrality of body and swivel table makes them extremely stable
> Reliability, lower noisy, easy to handle
The Main Parameters:
Working ranges | ≤1200mm | |
Cutting angle | 0~67.5° | |
Cutting angle error | ≤1° | |
Line speed | 0~250m/min | |
Feed speed | Adjustable | |
Working voltage | 380V 50Hz | |
Total power | 6.25KW | |
Total weight | 7000KG | |
Packing | Cases | 5 Plywood Cases |
Volume | 55 CBM |
