Haige steel wire cutting and stripping machine for sale Wire peeling machine type KP25:
From wire rod to bar:
1. composition parts
| Loader | 1set |
| Uncoiling machine | 1set |
| Pre-straightener | 1set |
| Peeling machine | 1set |
| polishing machine | 1set |
| coiling machine | 1set |
2. Process Description
Loader→Uncoil machine→Centerless lathe→Cutting machine→Charging basket
Main Technical Parameters:
Specification |
KP25 |
|
|
Requirements before Peeling |
Diameter range(mm) |
Φ8~Φ25 (without dead bending ) |
Yield strength σb(Mpa) |
≤900 |
|
Surface hardness |
≤HB320 |
|
Requirement for curvature(mm/m) |
peeling≤1. 5 but no dead blend |
|
Diameter tolerance |
d-2-GB/T702-2004 |
|
Roundness |
≤50% of diameter tolerance |
|
Surface roughness(Ra) |
≤25mm |
|
After Peeling |
Dia peeling depth(mm) |
0.5~1.5 |
Diameter range(mm) |
Φ7.5~Φ23.5 |
|
Diameter tolerance |
≤IT10 |
|
Surface roughness(Ra) |
≤6.3μm |
|
Roundness (mm) |
≤0.03 |
|
Speed(stepless speed) |
1.0~8.0 m/min |
|
Motor of uncoiler machine |
15kw |
|
Feeding motor(uncoiler machine) |
2.2 kw |
|
Main motor (centerless lathe) |
45 kw |
|
Feeding motor (centerless lathe) |
4 kw x 2 |
|
Payment terms:
50% down payment by T/T
50% balance before shipment by T/T
We can solve the problem for you is :
1. After sales service:we will dispatch professional technicians to customer
factory for machine installation and training.
2. Our salesman will be 24 hours online for you to solve problems.
3. We have been in this business line for more than 15 years.
Our machine quality is the best in China.
Packing details:
Standard export packing: pallet+wooden box+plastic stretch film
Successful orders:
How to contact us ?
For more information ,pls feel free to let us know ! Hope to have a win-win cooperation! Thanks in advance!
