Carton box automatic flexo printing and slotter machine
Features:
Paper feeding section
1.Automation chain paper feed
2.Postion fexing ensures precise paper feeding.
3.Automatic counting.
Printing section
1.Planetary transmission and electrical positioning.360-degree adjustment in both dynamic and static condition.
2.The embossing rollers get apart from printing template oned machine stops.
3. The upper ink roller is equipped with load-free system that prevents ink from getting dried when machine is running.
4.Colors of 1 to 4 can be combined easily.
5. Pneumatic siphon ink supply circulation system.
Lighting system
1.The printing roller is equipped with template hang-on device.
2.Step pedal is sued to control the side of printing plate when in mounting and dismounting.
3.The phasing may an item side,the digital ides decide may
Slotting section
1.360-degree adjustment of grooving position.
2.Integrated movement of the four grooving blades.
3.Top-quality steel blades are used to guarantee smoothness in grooving.
4.Gear are made of 45# forged and high frequency steels that makes no-gap transmission.
5.Transmission gears are joined together with no bonds,which ensures long-tem printing precision.
6. Dip-in lubrication guarantees long life.
7.Electrical shit technology and pneumatic interlock is used on printing section and grooving section.
8.Imported electrical appliances and bearings are used.
Main technological parameters
Model(Unit:mm) |
1200*2200 |
1400*2600 |
1400*2800 |
1600*2800 |
1800*3000 |
Maximum feeding size |
1200*2000 |
1400*2450 |
1400*2650 |
1600*2650 |
1800*2850 |
Minimum feeding size |
350*350 |
350*350 |
350*350 |
450*450 |
500*500 |
Maximum printing breadth |
1150*1800 |
1350*2200 |
1350*2400 |
1550*2400 |
1750*2600 |
Maximum slotting size |
7*300 |
7*350 |
7*350 |
7*400 |
7*450 |
Maximum slotting clearance |
100 |
110 |
110 |
120 |
130 |
Slotting blade thickness |
7 |
7 |
7 |
7 |
7 |
Standard printing plate thickness |
7 |
7 |
7 |
7 |
7 |
Maximum speed |
70 |
65 |
65 |
60 |
50 |
Maximum height of pushing paper |
-200mm |
-200mm |
-200mm |
-200mm |
-200mm |
Minimum height of pushing paper |
300mm |
350mm |
350mm |
450mm |
500mm |
Min feeding size |
300*400 |
350*400 |
350*400 |
450*500 |
500*600 |
