ZK-C Carton Forming Machine

Specifications

Carton Forming Machine
>Semi-auto paper feeding
>Auto counting system
>Choice grooving blade
>With lighting system

                                                   ZK-C Carton Forming Machine



This kind of machine is used for corrugated cardboard cutting, line pressing, slotting and corner cutting. Indispensable device for carton box factory.



Features:

• Semi-auto paper feeding by chain.
• Reconfirmed position fixing ensures accurate paper feeding.
• All shafts are grinded and plated with chrome.
• All gears are lubricated centrally, which makes low noise and stable running.
• Planetary transmission, electrical image positioning.
• Integrated movement of the four grooving blades.
• Auto counting system is optional for precise control of working speed.
• Choice grooving blades are used.
• Both 4-shaft and 6-shaft forming machine can be used.
• Equipped with lighting system.
• Imported electrical appliances and bearings are used.



Main technological parameters



Model(Unit:mm)	1200*2200	1400*2600	1600*2800	1800*3000
Breadth	2200	2600	2800	3000
Maximum feeding size	1200*2000	1400*2400	1600*2600	1800*2800
Minimum feeding size	280*280	300*300	420*420	500*500
Maximum grooving size	7*300	7*350	7*400	7*450
Minimum grooving clearance	100	100	100	120
Grooving blade thickness	7	7	7	7
Machine overall dimensions	3150*3150*1400	3550*3200*1400	3850*3300*1500	4050*3450*1600
Maximum speed	70pages/min	60pages/min	60pages/min	50pages/min
Weight (ton)	2.6T	3T	3 .5	4.5T
Power rate	2.2KW	3KW	4KW	5.5KW
