Help CenterJY60 Gener Four Pillars Two-rolls Precision Fine Steel Bar Straightening Machine
Related Products
-
China JY80A Frame Structure Two Rollers Vertical Straightening Machine for Round Steel BarNegotiableMOQ: 1 Set -
JY100Z Straightening Macine for Round Steel BarNegotiableMOQ: 1 Set
-
Frame Straightening Machine for Round Steel BarsNegotiableMOQ: 1 Set
-
Frame Type Straightening Machine for Round Steel BarsNegotiableMOQ: 1 Set
-
Straightening MachineNegotiableMOQ: 1 Set
Specifications
JY60 two-rolls steel bar straightening machine1. easily operate
2. auto loading and unloading bar
3. low labor cost
TWO-ROLLS FINE STRAIGHTENING MACHINE--JY60
1. Processing Diameter Range: 18~60mm
2. Straightening Speed: 2.5~12m/min
3. Straghtness ≤0.3m/mm
Contact:
Lily
Skype ID: haige.lily
QQ:867033424
Specification |
JY60 |
|||
|
Raw
Material
|
Diameter Range(mm) (excluding drawingmaterial) |
Tensile Strength σb≤450(M pa) |
Φ18≤d≤Φ60(L ≥2000) |
|
Tensile Strength σb≤1000(M pa) |
Φ18≤d≤Φ58(L ≥2000) |
|||
Surface Hardness |
≤HB380(≤HRC42) |
|||
Straightness(mm/m) |
≤3 |
|||
Diameter Tolerance |
Bright Steel ≤IT10 |
|||
Circular Degree |
d≤50 |
≤50% of diameter tolerance |
||
50<d≤60 |
≤65% of diameter tolerance |
|||
|
Diameter Range(mm) (excluding drawingmaterial) |
≤3.2mm~6.3mm |
|||
|
Finished
Products
|
Straightness(mm/m) |
Bright Steel≤0.30 |
||
Diameter Tolerance |
Bright Steel≤IT8 |
|||
Surface Roughness(Ra) |
Bright Steel≤0.8μm |
|||
Roll Quantity (Pcs) |
2 |
|||
Roll Diameter(mm) |
Φ260 |
|||
|
Straightening Feeding Speed(m/min) (infinitely adjustable-speed) |
2.5~12 |
|||
Main Machine Motor Power (KW) |
30 X 2 |
|||
Lifting Motor Power(KW) |
3.0 |
|||
|
Main Machine Outline Dimensions (Length*Width*Height) |
||||
Weight |
8.0 T |
|||
Total Capacity |
70 |
|||
Compressed Air Source(user prepare by themselves) |
0.5~0.8MPa,1.8m3/min,twp-stage oil-water separator |
|||
