Specifications
CR3000A test bench is our latest indepentent researched special device to test the performance of high-pressure common rail pump
CR3000A test bench is our latest indepentent researched special device to test the performance of high-pressure common rail pump and injector, controlled by industrial computer, Windows operating system. The oil quantity is measured by sensor and displayed on computer screen(Electronic fuel delivery system). All data can be searched, saved, modified and made into database., and the database can be updated for free. It can provide 0~2000 bar of rail pressure and pressure controlled automatically, it can test common rail pump and injector of BOSCH,SIEMENS,DELPHI,DENSO. Advanced technology, steady performance, precise measurement and convenient operation.if the test bench has fault, it can diagnosis fault by remote assistance on internet, and the maintenance will be convenient and efficient.
>>>CHARACTERISTIC
1.Controlled by industrial computer in real time, Windows operating system.
2. Oil quantity is measured by sensor and displayed on 19" LCD
3. Data can be searched, printed and made into database.
4. It can provide 0~2000 bar of rail pressure.
5. Oil temperatue is controlled by computer
6. Drive signal can be controlled.
7. Protection function of short-circuit.
8. Rail pressure can be tested in real time, it contains the high-pressure protection function.
9. Pulse and frequency of the injector drive signal can be adjusted.
10.Injection time can be setted.
11.Precise measurement, easy operation, low noise.
12. fulfill the remote assistance by internet and make the maintenance easy to operate.
13. Forced cooling system(optional function)
14. TEST PIEZO INECTOR FUNCTION(optional function)
15. BOSCH DRV VALVE FUNCTION(optional function)
16. Checking Delivery Of CR PUMP(optional function)
>>>FUNCTION
Common Rail Injector |
Common Rail Pump |
|
1. Test brands:BOSCH,SIEMENS,DELPHI,DENSO. Piezo injector testing(optional function) |
1.Test brands:BOSCH,SIEMENS,DELPHI,DENSO. |
|
2.Test 4 pieces of injectors at a time. (6 is also available---optional function) |
2.Test the double plunger HP0 pump of DENSO—(optional function) |
3. Test the pre-injection of the high-pressure common rail injector. |
3. Test the sealing of common rail pump. |
4.Test the max. oil quantity of high-pressure common rail injector. |
4. Test the internal pressure of common rail pump. |
5. Test the cranking oil quantity of high-pressure common rail injector. |
5.Test the proportional electromagnetic valve of common rail pump. |
6. Test the backflow oil quantity of high-pressure common rail injector. |
6.Test the input pressure of common rail pump. |
7. Test the average oil quantity of high-pressure common rail injector. |
7.Test the flux of common rail pump. |
8. Test the high-pressure common rail injector's injection state and oil quantity measurement. |
asure the rail pressure in real time. |
9. Data can be searched, printed and made into database. |
9.Data can be searched, printed and made to database. |
>>>TECHNICAL PARAMETER
Injection testing frequency |
50~3000 rpm |
Pulse width |
0.1~200 ms |
Continuous injection times |
0~1000 |
Fuel temperature |
40±2 |
Supply oil quantity of common rail injector |
0~200cc/min0.5% |
Rail high pressure |
0~2000 bar |
Test oil filtered precision |
5μ |
Input power |
380V/50hz/3phase or 220V/60hz/3phase |
Rotation speed |
0~4000RPM |
Oil tank capacity |
60L |
Flywheel inertia’s moment |
0.8KG.M2 |
Center height |
125MM |
Output power |
7.5KW (11kw,15kw,18.5kw as request) |
standard export package
one year warranty
