Help CenterCR3000A-708 Common Rail System Test Bench for Common Rail Pump and Common Rail Injector Testing
Related Products
-
PQ1000 Common Rail Diesel Injection Fuel Injection Injector Test Bench With Bosch Piezo Injector FunctionUS$ 1,000 - 1,100MOQ: 1 Set -
Common Rail AccesoriesNegotiableMOQ: 1 Set
-
CR3000A-708 Common Rail System Test BenchUS$ 4,600 - 8,000MOQ: 1 Set
-
EPS200 Common Rail Injector Test BenchUS$ 3,800 - 4,400MOQ: 1 Set
-
NTS300 Common Rail Injector Test Bench/piezo Injector TesterUS$ 1,000 - 4,000MOQ: 1 Set
Optional Fuction:
1. One flow sensor(Injection,return oil.turn test)
2.Two Flow Sensors
Recommend,test fast,Injection,return oil ,test at the same time)
3Weight Sensor(Many injectors can tested at the same time,Test easily and quickly,Low requirements on temperature and oil quality)
4,DRV Valve And Pump Delivery Sensor,Used in CR PUMP Testin
5,Can Test Denso HP0 pump
6,Can Test Bosch,Siemens piezo Injectors
7.With CP1 PUMP
8,Injectors Mounting bracket, convenient and reliable injector clamping
CR3000A COMMON RAIL TEST BENCH is the professional test bench which is used for testing common rail system, can test common rail pump,common rail injector at same time.
1 Pump testing: pump delivery, pressure,PVC working status, leakage of itself,
2.Injector testing: leakage, injection oil quantity and back oil quantity(pre-injection,Idling, emissions, full load)
3.it can test pressure sensor,and DRV valve
4. Supports system: BOSCH,DELPHI,DENSO,SIEMENS
5. Testing data inside( pump and injector)
6. Electronic fuel delivery measuring, automatic detection.
Technical parameters
1.Motor power: 7.5KW, 11KW, 15KW, 18.5KW
2. Electronic power: 3 PHASE 380V or 3 PHASE 220V
3. Motor speed: 0-4000RPM
4. Presure adjustment: 0-2000bar
5. Flow testing range: 0-600ml/1000times
6.Flow measurement accuracy:0.1ml
7. Temperature range: 40+-2
8. Cooling system: fan or forced cooling
standard export pacakge
one year warranty
Main products include:
1, Diesel engine parts (nozzle, plunger, delivery valve, head Rotor, injector, fuel pump and other accessories) 2 Injection pump test bench 3 auto tools 4 Auto parts 5, special vehicles 6 , Turbocharger.......
We are the leading manufacturer in Diesel Injection Pump Test Bench and Turbo charger in CHINA, already sold more than 100 Countries, include EUI/EUP tester with Cam box, EDC VP37 tester, VP44 teser,RED4 EDC, HEUI tester, DENSO ECD-V3,V4,V5 pump tester,PT Cummins Pumps and Injectors tester, Common Rail injectors and Common Rail Pump tester( CRDI) and Turbo Charger, Spare parts(plunger, nozzle, head rotor, injector...) also different model tools for pump and injector repair.
