QH-9905 Paper Foodpail Machine
FIRST QUALITY , BEST SERVICE , EXPERIENCE , ONE STOP SOLUTION
QH-9905 Paper Foodpail Machine Picture:
QH-9905 Paper Food Pail Machine Description:
Data:
Description:
Paper Foodpail Machine (paper box forming machine) is an automatic machine, specialize in making food carton, box, container which are made from cardboard, paper, paperboard, corrugated paper etc.
The food box(carton, container, dish, tray) is widely used as burger box, hot-dog box(tray), one block box, food pail box(Chinese food box, take-away box), fries box(chips box, chips tray), lunch box, meal box, etc.
Advantage:
# Compact structure, Strong frame, keep the machine reliable and durable with low noise.
# Hard Plastic-glass cover, Safe and visible for user.
# Easy exchange molds to make different products, charging and adjusting time is very short.
# PLC program control the whole line, available to make complicated boxes.
# Automatic collection, stock, and count.
# Human being designed control button and panel, more easy and safe runs by user.
Technical Specification
Model: |
QH-9905 Paper Foodpail Machine Paper box forming machine |
||
Speed: |
Max. 180 box/minute |
||
Welding Method: |
Water-Glue System Welding; (Food grade glue, POLYVINYL-ACETATE EMULSION), |
||
Available Material: |
200~600gsm cardboard, paperboard, paper, film coated paper, etc. |
||
Material Thickness: |
Max. 1.5mm |
||
Power: |
3KW, |
||
Power Source: |
380V, 220V 50/60Hz, |
||
Machine Size (L*W*H): |
3450*1500*1450 |
Pack Size |
3530*1580*1600 |
Weight: |
2000KG; |
||
Air Source: |
Pressure: 6KG/cm2 ; (0.6MPa); Out-put: 200 L/minute ; (0.2~0.4 m3/minute); User Need To Buy Air Compressor |
||
Available to make machines and molds on user order. | |||
Standard Output Capacity :
|
One block paper box(4-corner box without cover), Boat Tray, |
Max. 180pcs/min; |
Fries box (chips box, chips tray): |
Max. 150pcs/min |
Burger box, hot-dog box, Lunch box |
Max. 120pcs/min |
Food pail (DEEP food box): |
Max. 100pcs/min |
Remark:
# The box size, box shape, material and its quality will affect the machine output.
# While the material is TWO-side FILM coated paper, or aluminum foil paper, should ADD hot melt glue system(Equipped On USER ORDER, USD13,000 Extra) to weld the box,.
Whole machine include: |
|
# Electric control box; |
# Feeding device; |
# Transfer System: |
# Water glue device ; |
# Forming(welding) device; |
# Collection device ; |
# One set of mold; |
|
|
ORDERED BY USER: |
|
# Hot melt glue system; |
# Air compressor and dryer . |
B
C
1, Are you trading company or manufacturer?
We are manufacturer, and also provide the business solution to all the friends.
2, Do you have quality certificate?
Yes we have CE, ISO etc.
3,What's the delivery time?
Around 20~30days, however, based on order.
4, Can you help us to buy other goods?
Sure of that, it is our honor to work for you, and control the goods quality.
Q1:what's payment terms ,trade terms you accept ?
Usually we appreciate T/T 30% deposit , then 70% balance is paid before shipment , we usually offer fob ningbo price .but we also accept other way like L/C , wetern union ,and do CFR&CIF etc.
Q2.how can i print it and cut it ?
solution1: buy printed and cutted paper cup fan from us
solution2: find the factory in your area to print and cut for you
solution3:buy the flexo printing machine and die cutting machine to print and cut by yourself .
if you are new in this field ,i suggest you'd better to adopt solution 1 or 2 when you are in first stage.
Q3.does it easy to operate and what can i do if it doesn't work?
First ,our machine is stable and easy to operate by one man ,what you do is just learn some basic thing like wet the paper cup fan , lubricating the moving parts regularly .And we will sent you manual and video ,we suggest you to come to visit our factory to learn more thing by yourself , and if there is something goes wrong , you can call us ,video-chat ,email us .And we will give solutions within 36 hrs .Our engineer also can be distributed to overseas as you required.
Q4. if the machine's spare parts broken ,where can i get ?
We will give you the spare parts which is vulnerable , and some critical parts like gear box , our quality is good ,in case it broken within one year ,we will sent you for free.
D
Our Service:
We offer not only the products, but also the solutions.
For all of our machines, we provide:
lOperation Manual, Operation or repair Video,
l1year guarantee, 1Year spare parts packing together with the machine,
l24-hours Email technical support, we will do our best to help the clients solve any question or problems.
lAvailable to send our engineer to clients factory, to install the machines, train the workers, repair the machines.
