Unique advantages of this product:1, the realization of high frequency and high frequency circuit. 2, the process does not produce noise. 3, no electric spark. 4, there will be no electromagnetic interference. 5, the service life is longer than the life of the common electromagnetic relay.Often used in controlMotor, bulb, LED lamp, DC motor, micro pump, solenoid valve, etc..
This product has two major categories of functions, can basically meet the general needs, the need for other requirements can also be customized;
Functional mode customers can set their own free, power automatically memory of the last set of functions and time, easy to use.
One function:P-1:
Give signal1, OUT1 output, time delayAfter automatic stop.
Give signal2,OUT2 output,Delay TimeAfter automatic stop.
stayDuring the delay period,Trigger free settings again:
A: once again, the trigger is invalid;
BAgain to trigger the re timing;
CReset the timer again, and the motor will stop at once.
If the delay time is set to0;
Give signal1, OUT1 output, keep output;
Give signal2, OUT2 output, keep output;
Two function:P-2:
Do not need the signal end, the electric motor turns to work automatically;
Concrete working mode:stop itY(seconds, minutes)-OUT1 work(seconds, minutes)-stop itY(seconds, minutes)-OUT2 work...... .Circulation work....... .Circulation work.
If the delay time is set to0;
Concrete working modeOUT1 work(seconds, minutes)-OUT2 work(seconds, minutes)-OUT1 work(seconds, minutes)-OUT2 work(seconds, minutes)......... .Circulation work.
Time range of modulation and delay:0.1Second99.9Seconds,1Seconds to999Seconds,1Minutes to999Minutes, customers can be arbitrarily adjusted.
