steel coil weight calculator
- 15000 Ton / Tons per Month
- Tianjin Xingang
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Standard: | AISI, ASTM, BS, DIN, GB, JIS, Other, AISI, ASTM, BS, DIN, GB, JIS, A653M,EN10327,GB/T2518-2008 | Grade: | hot dip galvanized steel coil, CS,SGCC,01,DX51D+Z | Thickness: | 0.15-1.2MM |
Place of Origin: | Shandong, China | Brand Name: | HX | Model Number: | SS grade 33-80,SGCC, SGCH, SGCD1-SGCD3, SGC340-SGC570, SGCC, DX51D |
Type: | Steel Coil | Technique: | Cold Rolled | Surface Treatment: | Galvanized |
Application: | Other, structural use,roofing,commercial use,household appliance,industry | Special Use: | High-strength Steel Plate | Width: | 600-1500mm |
Length: | any length, depends on the coil weight |
Product Description
Specifications
steel coil weight calculator1.Thickness:0.13-1.20mm
2.Width:600-1250mm
3.Zinc coating:60-275gsm
Steel coil weight calculator
Steel grade: DX51D,SS grade 33-80 SGCC Q195
Discount for large quantities
Competitive price from our own factory.
Products information:
Hot dip galvanized steel coils are produced by immersing steel in a zinc bath.
An appropriate galvanizing process requires a pretreatment process during which the steel passes
through different baths which prepare the surface for zinc coating.
In this stage, chemicals are used to clean the surface of the steel. After the chemical treatment,
the steel coils pass through a bath of melted zinc at temperatures around 460 ° C. The resulting uniform
coating is finished through a process of skin-passing to provide smooth and shiny
appearance of the finished product.
To store for a longer period, the hotdip galvanized coils can be delivered with a final oil coating,
according to the customer’s demand.
PROFILAND STEEL produces hot-dip galvanized steel coils with very good workability
at further cold forming and bending processes.
Technical specification for the hotdip galvanized :
• Steel grade: DX51D+Z
• Zinc coverage: 30-180 g/sqm on both sides (depending by the requested specification);
• Thickness: between 0,2 mm and 1,00 mm;
• Width: 600mm,914mm,1000mm, 1220mm and 1250 mm;• Coil weight: 4-6 mt;
• Coil ID: 508 mm;
• Coil OD: 900-1500 mm ;
Depending on their usage, the hot-dip galvanized coil can be delivered slightly oiled.
The detailed information:
Commodity | Hot dip galvanized steel coil and sheet |
Techinical Standard: | JIS 3302 / ASTM A653 / EN10143 |
Grade | DX51D / DX52D/ DX53D/ S250,280,320GD |
Types: | Commercial / Drawing / Deep Drawing / Structural quality |
Width | 500/650/726/820/914/1000/1200/1219/1220/1250mm |
Thickness | 0.12-2.5mm (0.14-0.5mm is the most advantage thickness) |
Type of coating: | galvanized |
Zinc coating | Z60-275g/m2 |
Surface treament | chromed / skinpass/ oiled/slightly oiled/ dry/ anti-fingerprint |
Surface structure: | zero spangle / minimized spangle / regular spangle/ big spangle |
ID coil | 508mm or 610mm |
Coil weight | 3-8 MT per coil |
Package: | Properly packed for ocean freight exportation in 20''containers |
Application: | Industrial panels, roofing and siding for painting |
Price terms | FOB,CFR,CIF |
Payment terms | 30%TT in advance+70% TT or irrevocable 70%L/C at sight |
delivery time | 25 days after recepit of 30% TT |
Remarks | Insurance is all risks |
MTC will be handed on with shipping documents | |
We accept the third party certificatation test |
Technical data of hot dipped galvanized coil
Chemical Composition | ||||||
GRADE | C | Si | Mn | P | S | Ti |
SGCC/DX51D+Z | ≤0.10 | ≤0.50 | ≤0.60 | ≤0.10 | ≤0.030 | ≤0.020 |
DX52D+Z | ≤0.10 | ≤0.50 | ≤0.60 | ≤0.10 | ≤0.030 | ≤0.020 |
SGCD/DX53D+Z | ≤0.10 | ≤0.30 | ≤0.50 | ≤0.05 | ≤0.030 | ≤0.020 |
SGCE/DX54D+Z | ≤0.10 | ≤0.30 | ≤0.30 | ≤0.03 | ≤0.020 | ≤0.020 |
DX56D+Z | ≤0.10 | ≤0.30 | ≤0.30 | ≤0.03 | ≤0.020 | ≤0.020 |
Structural | ≤0.20 | ≤0.60 | ≤1.70 | ≤0.10 | ≤0.045 |
hot dipped galvanized steel coil Mechanical Properties | ||||||
GRADE | Yield Strength MPa | Tensile Strength MPa | Elongation % | |||
SGCC(DX51D+Z) | ≥205 | ≥270 | - | |||
SGCD(DX53D+Z) | - | ≥270 | 38 | |||
SGCE(DX54D+Z) | - | ≥270 | 40 | |||
DX56D+Z | - | ≥270 | 42 |
