bitumen waterproof membrane production line

 bitumen waterproof membrane production line

It is widely used in industrial and civil buildings, such as roof, basement, toilet, bridge, park, swimming pool, tunnel for waterproof and moistureprof. Bitumen is a hydrocarbon and is created naturally from crude oil. It is a useful carbon store and does not generate greenhouse gases. The membrane is therefore a sustainable way of storing carbon on the Earth's surface.

Advantage:

1. Rational structure

2. Low transportation, installation, adjustment cost

3. convenient to operation and repair

Production descriptions:

1 Production speed: 0-35m/min adjustable

2 Base materials:reinforcement sheet, fiberglass tissue

3 Modified MaterialsSBS, APP etc.

4 Surfacing sand,Schist, PE film.

   One side: PE film; another side: sand or slate flakes

   PE film on both sides.

   Embossed or plain.

5. Function: Can produce SBS/APP modified bitumen membrane, self-adhesive modified bitumen membrane. All functions in one line, or in single line. According to customers requirements we can make different design.

6.We co-operate with the best research center in water-proofing field in China, can offer you the best design and assure you the best quality

1.1   Roll unfolding device

1.2   Intermediate feed device

1.3   Reinforcement connecting device (By means of double sides pressing board ,the device press the material on one side, daubs chemical glue on the material on the other side, which makes the materials mixed together automatically and reduces the defective goods rate because of reinforcement joints to the greatest extent)

1.4   Reinforcement drying device(No need to stop the operation while reinforcement jointing it, releases and dry reinforcement automatically, reinforcement auto rectifying and intermediate feed device it adjusts the trend of reinforcement by means of photo electricity. Intermediate feed makes the equipment more humanized.)

1.5   Auto rectifying device (this device adopts the technology of photo electricity auto rectifying to ensure the trend of roll in the operation of the equipment, which makes the membrane produced winder tidy and beautiful.)

1.6   Impregnation tension control device (Extrusion by cylinder, asphalt coating roll impregnation can be adjusted up-down. It adopts unique reinforcement tension control.)

1.7   Asphalt coating device(Coating asphalt twice which can adjust the position of reinforcement in the coiled material ,meanwhile it can ensure the coiled material workability,electronic digital show the thickness ,In control of electronic instrument accurately, it can master the exact thickness of coiled material . During each class production, the rest few raw materials can be returned to the mixing system directly. The flue gas environmental protection system of preimpregnated asphalt coating adopt closed overall frame form which use the method of ejecting smoke in petticoat pipe and absorbing smoke outside.

1.8   Sand-scattering device(This set of device adopts the technology of automatic tracking and rectifying sanding , which reduces the waste of sand to the greatest extent , and control sand box and roil with power-driven device

1.9   Sand-lifting device

1.10 Filming and thickness-measuring device  (from the device of adjusting film mulching,we can regulate the positions of the coiled material and membrane which makes the membrane move in the trend of oiled material .the advantage of it is reducing the defective goods produced by filming.and the powe-driven lifting technology can saving manpower in the filming process.

1.11 Sand-pressing with suspending device (Suspending and cooling device.entended 10-15 meters which speed up the cooling effect to a certain extent.Advanced thickness measurement device detects the products quality to ensure the thickness of the stability and products’ high quality.)

1.12 Cooling and embossing device

1.13 Finished products storage device

1.14 Traction-spring device

1.15 Auto winder device (Inverter computer programming and touch screen synchronized control it. Conveying felt, counting, cutting felt, gluing tape, propelling felt and rolling are all automatic.

Native machine has the characteristics of the operation diversification:you can choose full-automation, circulation , steping,manual and a series of operations     . automatic rolling machine is suitable for high yield big production line.)

1.16 Electrical operating control device

1.17 Mixing-weighing system device

1.18 horizontal storage tanks

1.19 Powder-conveying system (Material delivery-metrological control system, one of human-computer interface control system, is a latest developed intelligence system by our company , it overcomes many defects in traditional powder conveyor and has the characteristics with flexible operation, lighten work intensity, simple parameter set, low failure rate, maintenance-free, visual display interface,etc. It is an upgrading product in transfer powder delivery system. The process flows are as following: First, with PLC control, storage tank delivery material to charger through pneumatic valve. Next supply the material to gauging tank from spiral conveyer. Third, it shows the needed material quantity by electronic balance, and carries the material to spiral conveyer pass sealed feeders. At last, feed the material to each agitator tank by PCL controlling. If you need to choose several working process, then directly select the agitator tank which you need on PCL control panel )

1.20 Smoke purification device

1.21 Heating with boiler system

1.22 Enclosed with product specification

It all depends.

If you order to us ,we must promise the quality ,if some quality problem happened,

1)We will dispatch our Quality and Problems Appraisers to make a confirmation

2) Have a negotiation of the compensation and sign agreements

3) Our After-Sales Department will perform the duties as the agreements.

Weifang Xuxin Waterproof Materials Co., Ltd. is a unit of China Building Material Market Association, Chinese waterproof materials

 Industry Association member units, and has achieved "elastomer (SBS) modified bitumen membrane" issued by the National

Building Materials Bureau the asphalt composite fetal flexible waterproofmembrane "industrial products production license;

obtain new products and new technology development program in Shandong Province, has made the" promotion the license

"Zhunyongzheng" made Qingdao, Jinan, Zibo City Shandong Provincial Construction Committee issued "quasicertificate ",

Shanghai and Sichuan Province" Zhunyongzheng the the.Xu Xin quality products, complete specifications, adhere to the starting

point, high standard, highquality, highefficiency approach to actively introduce technical personnel, the road of science and

technology plant. The quality of the company to survive, with credit extension development, and provide a comprehensive after-sales service, sincerely welcome friends from all walks of life to visit.
