Specifications
Light Pole Polishing Machine1.ISO&CQC cetificate
2.20 years manufacturing experience
3.Used to grinding pipe
4.ISO9001
ZDMJ Automatic Light Pole Polishing Machine
Description:
This machine is automatic running under pipe self rotating and grinding machine moving. On grinding machine ,there installed flap wheel, flap wheel grind on the surface of pipe,suitable for galvanized and stainless pipe surface. The speed is quick and simple operation. It is with high efficiency, saving personnel and power. It is the good machine for grinding pipe surface.
Feature:
1.Apt to light poles grinding. Various pole body can be burnished and grinded.
2.Automatic recovery, environmentally friendly and also can recycle the zinc powder.
3.Using abrasive belt for grinding, low cost, fast, saving manpower. Smooth finish of the pole body is high after burnishing and grinding. The speed can be adjusted at will.
Specification:
Model |
Pole length (mm) |
Pole diameter (mm) |
Polishing speed (mm/min) |
Net weight (kg) |
External dimensions L×W×H(mm) |
| ZDMJ350×12000 |
12000 (can lengthen) |
Φ60- Φ350 | 300-1000 | 1500 | 14500×2200×1600 |
| ZDMJ500×14000 |
14000 (can lengthen) |
Φ60- Φ500 | 300-1000 | 2200 | 16500×2200×1600 |
Main Accessories:
SN |
Name |
Spec |
Qty |
1 |
flap wheel motor |
1.5 kw |
2sets |
2 |
walking adjust motor |
0.55kw |
1set |
3 |
rotating electrical motor |
0.55 kw |
1set |
4 |
reducer |
bwd150 |
1set |
5 |
rotary reducer |
bwd150 |
1set |
ZDMJ Automatic Light Pole Polishing Machine :
Automatic Metal Polishing Machine:
If you are interest in our products or our services, please contact us, you will get the best reliable products in reasonable prices !
