Specifications
WG Mechanical Gradually Pipe Bender1.Curing spot don't distort
2.Maintail original shape
3.Easy operation
4.Low price
WG Mechanical Gradually Pipe Bender
Description:
This equipment composed by the board and bending mode, with two sets of molds. Direct mode traction motor reducer, will die on the pressure in the round steel bar along the curved arc surface, simple operation, without heating and filler, economic benefits, compared with the industry's large-scale bending machine is similar effect, is Steel manufacturer of equipment necessary.
Feature:
1.Our company produces the WG machinery advances gradually the type pipe bending machine, specially designs the manufacture for the light post enterprise, is the domestic origunation.
2.This machine is suitable for each kind of cone-shape illumination light post forehead curving, the curving spot does not distort, the circular cone pole, the polygon pole maintains the original shape, the price is low.
Specification:
|
Curvig pipe diameter |
Bending radius (mm) |
The main motor power (kw) |
Net weight (kg) |
L×W×H External dimensions (mm) |
WG90×4 |
90×4 |
R500-R700 |
3 |
2000 |
3700×3050×620 |
WG100×4 |
100×4 |
R600-R1000 |
3 |
2500 |
4300×3250×620 |
WG100×4 |
100×4 |
R1200-R1500 |
3 |
3000 |
4500×3460×620 |
Parameters:
No. |
Model |
Value |
Unit |
Note |
|
1 |
BENDING DIAMETER |
φ90 |
mm |
|
|
2 |
BENDING RADIUS |
R500,R700 |
mm |
2 sets of round mould |
|
3 |
BENDING TUBE THICKNESS |
4 |
mm |
|
|
|
4 |
MOTOR POWER |
model |
Y132S-6 |
mm |
|
power |
3 |
KW |
|
||
Rotate speed |
960 |
rpm |
|
||
|
5 |
SIZE |
L |
3000 |
mm |
|
W |
2300 |
mm |
|
||
H |
620 |
mm |
|
||
6 |
WEIGHT |
2300 |
kg |
|
|
WG Mechanical Gradually Pipe Bender :
If you are interest in our products or our services, please contact us, you will get the best reliable products in reasonable prices !
