Specifications
ZMDJ Wide Belt Sander1.Easy to polish various pipe
2.Using sand belt grinding
3.Enviromental friendly
4.ISO9001 certify
ZMDJ Wide Belt Sander
Description:
This machine is automatic running under pipe self rotating and grinding machine moving. On grinding machine ,there installed flap wheel, flap wheel grind on the surface of pipe,suitable for galvanized and stainless pipe surface. The speed is quick and simple operation. It is with high efficiency, saving personnel and power. It is the good machine for grinding pipe surface.
1.This machine steel tube self-run and the movement of the machine in order to move the steel tube.
2.The machine is fitted with grinding polishing bar, these grinding polishing bars will grind and polish the surface of steel tube quickly.
Feature:
1.Polish yard quick and easy to carry out various body-polishing polished
2.Automatic recovery , is environmentally friendly and also the recovery of zinc powder
3.Using sand belt grinding , low cost, fast, saving manpower . After polishing polished finish on the high-speed regulation can be arbitrary.
Specification:
sn |
name |
value |
unit |
remark |
|
1 |
grinding pipe diameter |
ø350 |
mm |
|
|
2 |
grinding pipe length |
14000 |
mm |
can be lengthened or shortened |
|
3 |
steel pope rotation speed |
5-10 |
rev./min |
|
|
4 |
grinding running speed |
1100 |
mm/min |
|
|
5 |
machine size |
l |
17500 |
mm |
|
w |
2000 |
mm |
|
||
h |
1800 |
mm |
|
||
6 |
machine weight |
1950 |
kg |
|
|
| Model | Pole Length(mm) | Polish Speed(mm/min) | Pole Diameter(mm) | Net Weight(kg) | External Dimensions(mm) |
| ZMDJ350×12000 | 12000 | Φ60-Φ350 | 300-1000 | 1500 | 14500×2200×1600 |
| ZMDJ500×14000 | 14000 | Φ60-Φ500 | 300-1000 | 2000 | 16500×2200×1600 |
Main accessories:
sn |
name |
spec. |
qty |
1 |
flap wheel motor |
1.5 kw |
2sets |
2 |
walking adjust motor |
0.55kw |
1set |
3 |
rotating electrical motor |
0.55 kw |
1set |
4 |
reducer |
bwd150 |
1set |
5 |
rotary reducer |
bwd150 |
1set |
ZMDJ Wide Belt Sander :
If you are interest in our products or our services, please contact us, you will get the best reliable products in reasonable prices !
