Microwave Vacuum Kasuri Methi Leaves Drying Equipment
Microwave Vacuum Dryer Machine is mainly used for the drying of different heat sensitive materials, such as polysaccharides, high starches
and materials with much oil. Moreover, it can also used for the drying, dehydration and enrichment processing of many easy oxidation materials.It has been widely used by food factory,medicinal factory and other for fruit,vegetable,meat and nut,fish ,mushroom and other materials drying.It can help to keep the mateirals cocoler,taste and just reduce the moisture by microwave that is very clean and healty!
Working principle of this machine
When equipment work, microwave through the microwave generator produced, the feed device input microwave heater.Material in the transmission system to the heater when material under the action of water in the microwave to heat up in the evaporation, water vapor through a wetted system and achieve the purpose of drying. Bacterium material was produced under the action of microwave electromagnetic field biological effect and heating effect. Due to the effect of microwave is directly in the material, so the drying temperature is low, the speed is quick, the loss of effective ingredients of drugs is very small.
Features of this drying equipment
Microwave Vacuum Dryer Machine makes use of both the microwave technology and the vacuum technology. It has many advanced features than the traditional drying ways!
(1)Heating evenly
Regardless of how each part of the object shape, microwave heating can make objects in the list at the same time even penetrate electromagnetic waves and generate heat. So it heats evenly,coke endogenous phenomenon will not occur.
(2)Energy-saving and higly-effecient
Since the material containing water is easy to absorb the microwave to generate heat,so it is efficient and energe-saving. It can save energy over 13 compared with infrared heating.
(3)Low temperature, good quality, mouldproof, moth-proofing, sterilization and preservation.
Due to the microwave vacuum heating,Microwave Vacuum Dryer can sterilize,prevent mould and dry at low temperature. This will make the materials keep its color,taste and avoid be oxidation!
(4)Safe, healthy and environmentally friendly.
Because the microwave energy is in metal heating indoor and waveguide, there is almost no microwave leakage.
Microwave Vacuum Dryer Machine makes use of both the microwave technology and the vacuum technology. It has many advanced features than the traditional drying ways!
Technical parameters:
Item Unit |
HWZ-5B |
HWZ-10B |
HWZ-15B |
HWZ-20B |
HWZ-25B/30B |
Microwave Power |
5 |
10 |
15 |
20 |
25-30 |
Microwave Frequency |
2450 |
2450 |
2450 |
2450 |
2450 |
Supply Voltage |
380±10% |
380±10% |
380±10% |
380±10% |
380±10% |
Area ofspreading materials |
0.75 |
0.75 |
2.25 |
2.25 |
3.4 |
Sterilization Capability |
10 — 20 |
||||
Dehydration Speed kg/ kw .h |
0.8—1.0 |
||||
Dehydration Temperature °C |
30—100 |
||||
External dimension (L*W*H) |
1290*1190*1880 |
1580*1190*1880 |
1780*2000*2140 |
1780*2000*2140 |
1880*2400*2420 |
