Double Hook Drop Forged US Type Turnbuckle

Double Hook Drop Forged US Type Turnbuckle thumbnail-1
Double Hook Drop Forged US Type Turnbuckle photo-1
US$ 0.3 - 50 MOQ: 1 Ton
Key Specifications
Get Latest Price
Material:
Other, 45# Carbon Steel,Stainless Steel
Contact Supplier Request Quote Chat Now
Qingdao Sail Rigging Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Material Other, 45# Carbon Steel,Stainless Steel

Specifications

Double Hook Drop Forged US Type Turnbuckle
Type:US
Material:stainless steel,carbon steel 45#

Double Hook Drop Forged US Type Turnbuckle



Turnbuckles Type:US,JIS,DIN,Commercial
Material:stainless steel,45#,Q235,Malleable Iron



Turnbuckles is one of our main products. We export turnbuckles worldwide and get approval from every customers on both price and quality.



Double Hook Drop Forged US Type Turnbuckle





  Working
load
limit
(lbs) 		  Dimensions(in)
Thread Dia
&
Take Up 		Weight
Each
(lbs) 		A B C
Closed 		D
Open 		E
Closed 		F G
1/4x4 400 0.3 0.25 0.45 1.59 11.94 7.94 1.27 4
5/16x41/2 700 0.47 0.31 0.5 1.94 13.81 9.31 1.5 4.5
3/8x6 1000 0.75 0.38 0.56 2.3 17.72 11.72 1.77 6
1/2x6 1500 1.6 0.5 0.66 2.94 19.38 13.38 2.28 6
1/2x9 1500 1.83 0.5 0.66 2.94 25.38 16.38 2.28 9
1/2x12 1500 2.08 0.5 0.66 2.94 31.38 19.38 2.28 12
5/8x6 2250 2.75 0.63 0.84 3.69 21.25 15.25 2.81 6
5/8x9 2250 3.13 0.63 0.84 3.69 27.25 18.25 2.81 9
5/8x12 2250 3.5 0.63 0.84 3.69 33.25 21.25 2.81 12
3/4x6 3000 3.89 0.75 0.98 4.52 23.28 17.28 3.33 6
3/4x9 3000 4.61 0.75 0.98 4.52 29.28 20.28 3.33 9
3/4x12 3000 5.43 0.75 0.98 4.52 35.28 23.28 3.33 12
3/4x18 3000 7.25 0.75 0.98 4.52 47.28 29.28 3.33 18
7/8x12 4000 8.1 0.88 1.13 5.19 37 25 3.78 12
7/8x18 4000 9.95 0.88 1.13 5.19 49 31 3.78 18
1x6 5000 9.33 1 1.25 5.84 26.69 20.69 4.25 6
1x12 5000 11.93 1 1.25 5.84 38.69 26.69 4.25 12
1x18 5000 14 1 1.25 5.84 50.69 32.69 4.25 18
1x24 5000 17.25 1 1.25 5.84 62.69 38.69 4.25 24
11/4x12 6500 19 1.25 1.5 7.22 41.56 29.56 5.13 12
11/4x18 6500 23 1.25 1.5 7.22 53.56 35.56 5.13 18
11/4x24 6500 27 1.25 1.5 7.22 65.56 41.56 5.13 24
11/2x12 7500 27.5 1.5 1.88 8.34 44.44 32.44 5.75 12
11/2x18 7500 31 1.5 1.88 8.34 56.44 38.44 5.75 18
11/2x24 7500 37.5 1.5 1.88 8.34 68.44 44.44 5.75 24



Material : Carbon steel, Stainless steel,

Surface: Hot dipped galvanized,   galvanized, Self- color

Packing: Carton+Pallet

Special Service: Special Specifications and Marks can be made according to customer' need!



Please don't hesitate to contact us if you have any interest in our products.



 We are looking forward to receiving your inquiry.



Double Hook Drop Forged US Type TurnbuckleDouble Hook Drop Forged US Type TurnbuckleDouble Hook Drop Forged US Type Turnbuckle
