Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Silent Diesel Generating Set 5kva
Silent Diesel Generating Set 5kva
US$ 490 - 510
MOQ: 5 Sets
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
KAIAO
Model Number:
KDE6700T3
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Plate Compactor KGC100NegotiableMOQ: 10 Cartons -
10Hp Power Farming Tiller KDT910NegotiableMOQ: 10 Sets
-
3 Inch Single Stage Recoil Start Centrifugal Gasoline Water Pump for Irrigation Use (KGP30)US$ 76 - 99MOQ: 30 Sets
-
8hp Air Cooled/ 186FAE Diesel Engine/ Roller Compactor( KDR800E) HOT SALE!!NegotiableMOQ: 5 Sets
-
Double Drum Vibratory Hand Roller Compactor With Diesel Engine KA186FAENegotiableMOQ: 5 Sets
Place of Origin
Jiangsu, China
Brand Name
KAIAO
Model Number
KDE6700T3
Output Type
AC Three Phase
Speed
3000/3600
Frequency
50/60
Rated Power
5.5/6.3
Rated Voltage
230/400
Rated Current
7.9/8.7
| Diesel generator KDE6700T3 | ||
| Generator Model | KDE6700T3 | |
| Frequency (Hz) | 50 | 60 |
| Output power (KVA) | 5.5 | 6.3 |
| Max. Power(KVA) | 6 | 7 |
| Voltage (V) | 230/400 | 240/416 |
| Current (A) | 7.9 | 8.7 |
| Engine speed (r/min) | 3000 | 3600 |
| Phase | 3-phase | |
| Power facter | 0.8 | |
| Excitation system | Self-excited constant voltage | |
| Noise level (7m) | DB (A): 72 | |
| Fuel tank capacity (L) | 15 | |
| Structure | Slient | |
| Panel | Ordinary | |
| Outputsocket | One single-phase,and one 3-phase | |
| Output terminal post | No | |
| DC12V output | Terminal post | |
| Net weight | 170 | |
| Dimension(L*W*H) | 912×532×740 | |
| Engine Model | KA186FA | |
| Engine Type | Single-cylinder, vertical, air-cooled, direct injection,four-stroke | |
| Bore*stroke (mm) | 86 *72 | |
| Displacement (L) | 0.418 | |
| Power (KW) | 5.7/3000 | 6.3/3600 |
| Fuel consumption rate (g. KW/h) | 275.1 | 281.5 |
| Compression ratio | 19 | |
| Lubrication system | Spring | |
| Engine starting system | Electric starter | |
| Diesel oil model | Summer: 0#, winter: -10# | |
| Lube oil model | SAE10W-30 (above CD grade) | |
| Lube oil capacity (L) | 1.65 | |
| Battery capacity(V-AH) | 12V-36Ah | |
