KDE300EW Diesel Welder Generator

Name: KDE300EW Diesel Welder Generator
Brand: KAIAO
SKU: 104347477
Availability: InStock

Negotiable MOQ: 5 Pieces (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

KAIAO

Model Number:

KDE300EW

Wuxi Kaiao Power Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name KAIAO

Model Number KDE300EW

Voltage 230/240

Current 13.0/13.3

Rated Duty Cycle 50%

Dimensions 930*690*920

Weight 200KG

Specifications

1.more reliable performance,
2.wheeled mobile,
3.easy to operate,
4.CE&ISO9001-2000 approved
5.High quality

Welding generator KDE300EW
Generator Model	KDE300EW
Frequency (Hz)	50	60
Output power (KVA)	3	3.2
Voltage (V)	230	240
Current (A)	13	13.3
No-load welding voltage(V)	60
Rated welding voltage(V)	26-30
Rated welding DC A	300
Current adjusting extenstion (A)	50-300
Electric welding load rate	50%
Engine speed (r/min)	3000	3600
Phase	Singe-phase
Power facter	1
Excitation system	Self-excited constant voltage
Noise level (7m)	DB (A): 77
Fuel tank capacity (L)	25
Structure	Open-frame
Panel	Ordinary
Outputsocket	Two
Output terminal post	No
Net weight	200
Dimension(LWH)	930690920
Engine Model	KA186FA
Engine Type	Single-cylinder, vertical, air-cooled, direct injection,four-stroke
Bore*stroke (mm)	2- 86 *72
Displacement (L)	0.836
Power (KW)	10.3/3000	11.3/3600
Fuel consumption rate (g. KW/h)	<340	<340
Compression ratio	19
Lubrication system	Spring
Engine starting system	Electric starter
Diesel oil model	Summer: 0#, winter: -10#
Lube oil model	SAE10W-30 (above CD grade)
Lube oil capacity (L)	1.65
Battery capacity(V-AH)	12V-36Ah
