2kw Diesel Welding Generator Machine (KDE6500TW)
Negotiable
MOQ: 10 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
KAIAO
Model Number:
KDE6500TW
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Jiangsu, China
Brand Name
KAIAO
Model Number
KDE6500TW
Arc Current
200A
Pulse Frequency
50/60HZ
Pilot Arc Current
50-200
Rated Duty Cycle
50%
Dimensions
640*480*530
Usage
DUAL-USE
Specifications
1.dual-use welding machine generator2. CE&ISO9001-2000 approved
3.economic use, long service life.
| Diesel generator KDE6500TW | ||
| Generator Model | KDE6500TW | |
| Frequency (Hz) | 50 | 60 |
| Output power (KVA) | 2 | 2.2 |
| Voltage (V) | 230 | 240 |
| Current (A) | 8.7 | 9.2 |
| No-load welding voltage(V) | 65 | |
| Rated welding voltage(V) | 26-30 | |
| Rated welding DC A | 200 | |
| Current adjusting extenstion (A) | 50-200 | |
| Electric welding load rate | 50% | |
| Engine speed (r/min) | 3000 | 3600 |
| Phase | Singe-phase | |
| Power facter | 1 | |
| Excitation system | Self-excited constant voltage | |
| Noise level (7m) | DB (A): 72 | |
| Fuel tank capacity (L) | 15 | |
| Structure | Slient | |
| Panel | Ordinary | |
| Outputsocket | Two | |
| Output terminal post | Two | |
| Net weight | 105 | |
| Dimension(L*W*H) | 640*480*530 | |
| Engine Model | KA186FA | |
| Engine Type | Single-cylinder, vertical, air-cooled, direct injection,four-stroke | |
| Bore*stroke (mm) | 86 *72 | |
| Displacement (L) | 0.418 | |
| Power (KW) | 5.7/3000 | 6.3/3600 |
| Fuel consumption rate (g. KW/h) | 275.1 | 281.5 |
| Compression ratio | 19 | |
| Lubrication system | Spring | |
| Engine starting system | Electric starter | |
| Diesel oil model | Summer: 0#, winter: -10# | |
| Lube oil model | SAE10W-30 (above CD grade) | |
| Lube oil capacity (L) | 1.65 | |
| Battery capacity(V-AH) | 12V-36Ah | |
*A dual-use machine with excellent performance allows the customers low cost
*With the features of easy arc striking with steady electric arc, and convenient adjustment of welding current(adjusting extension: 50-200A), the machine is suitable for the electrode 2.0-4.0mm diameter, which allows easy operation.
Run steadily.Small size.Light.With wheel.Easy moved.Very convenice.Fuel-efficient
A dual-use machine with excellent performance allows the customers low cost.
Diesel welding generator,Welding generator,Welder Generator,Diesel generator,Diesel generator.diesel welding generation unit
